SlotStatusBits - This is a 32 bit value. The lower 8 bits of this value are defined
as follows for FLEX I/O:
Related Communications
Modules Documentation For more information on ControlLogix communications modules, see the
following Rockwell Automation publications listed in Table 2.1:
These publications are available from Rockwell Automation at:
http://literature.rockwellautomation.com .
Module
0
Module
1
Module
2
Module
3
Module
4
Module
5
Module
6
Module
7
Table 2.1
Catalog
Number: Description:
Installation
Instructions:
User Manual:
1756-CNB ControlNet Communication
Module 1756-IN571 CNET-UM001
1756-CNBR Redundant ControlNet
Communication Module
