Rockwell Automation 1794 FLEX I/O System with ControlLogix for SIL2 - Manual (Page 10)

Publication 1794-RM001G-EN-P - December 2011
1-6 SIL Policy
I/O Modules -
Analog 1794-IE8 8 Input Analog Module B NA 1794-IN100 1794-UM002
1794-IF4I 4 Isolated Input Analog
Module A F, G, H, I, I.x 1794-IN038 1794-UM008
1794-IF2XOF2I 2 In/2 Out Isolated Combo
Module A F, G, H, I, I.x 1794-IN039 1794-UM008
1794-OE4 4 Output Analog Module B NA 1794-IN100 1794-UM002
1794-OF4I 4 Isolated Output Analog
Module A F, G, H, I, I.x 1794-IN037 1794-UM008
1794-IT8 Thermocouple Input Module A K, K.x 1794-IN021 1794-UM007
1794-IR8 RTD Input Module A K, K.x 1794-IN021 1794-UM004
1794-IRT8 TC/RTD Input Module B B, D, E, E.1,
E.x 1794-IN050 1794-UM012
1794-IJ2 2 Ch. Frequency Counter
Module A D 1794-IN049 1794-UM011
1794-IP4 4 Ch. Pulse Counter Module B 4, 4.x 1794-IN064 1794-UM016
I/O Modules -
Analog 1794-IE4XOE2XT 4 Input/2 Output Analog
Combo Module B NA 1794-IN125 NA
1794-IE8XT 8 Input analog Module B NA
1794-OE4XT 4 Output Analog Module B NA
1794-IF2XOF2IXT 2 Input/2 Output Isolated
Analog Combo Module A I, I.x 1794-IN129
1794-IF4IXT 4 Isolated Input Analog
Module A I, I.x
1794-OF4IXT 4 Isolated Output Analog
Module A I, I.x
1794-IF4ICFXT 4 Isolated Input Analog
Module A I, I.x 1794-IN130
1794-IJ2XT 2 Ch. Frequency Counter
Module A E, E.x 1794-IN049
1794-IRT8XT 8 TC/RTD Input Analog
Module B D, E, E.1, E.x 1794-IN050
Table 1.1 FLEX I/O Components For Use in the SIL 2 System
Device Type: Catalog Number:
(1)
Description:
Related Documentation
(4)
with More Information on
Catalog Number:
Series
(2)
Firmware
Revision:
(2) (3)
Installation
Instructions:
User Manual:
