Rockwell Automation Publication 1734-UM018B-EN-E - October 2013 17
Chapter
3
Configure the Adapter with RSLogix5000
software
Introduction This chapter guides you through the steps required to configure your modules
using the RSLogix 5000 software. Note that the modules presented in this
chapter can be configured using RSLogix 5000 software,
version 17, or later.
Before using your adapter in an EtherNet/IP network, you need to configure it
with an IP address, subnet mask, and optional Gateway address. This chapter
describes these configuration requirements and the procedures for providing
them. Here are ways you can do this:
• Use the Rockwell BootP/DHCP utility, version 2.3 or later, that ships
with RSLogix 5000 or RSLinx software.
–
You can also use this utility to reconfigure a device with an IP address
you must change.
• Use a third party DHCP server.
• Use the Network Address thumbwheel switches.
• Have your network administrator configure the adapter via the network
DHCP server.
See the table for where to find information in this chapter..
Topic Page
Configuration Requirements 18
IP Address 19
Gateway Address 20
Subnet Mask 21
Set the Network Address 22
Set the Network Address for POINT I/O Adapters 22
Use the Rockwell BootP/DHCP Utility 23
Save the Relation List 25
Use DHCP Software to Configure Your Adapter 27
Chapter Summary 27
