Rockwell Automation 1732E-IB16M12SOEDR EtherNet/IP ArmorBlock supporting Sequence of Events User Manual
Page 92
Publication 1732E-UM002A-EN-P - March 2010
84 1732E EtherNet/IP ArmorBlock Supporting Sequence of Events Data Tables
88-95
IN 3 Off-On Time Stamp (64 bit)
96-103
IN 3 On-Off Time Stamp (64 bit)
104-111
IN 4 Off-On Time Stamp (64 bit)
112-119
IN 4 On-Off Time Stamp (64 bit)
120-127
IN 5 Off-On Time Stamp (64 bit)
128-135
IN 5 On-Off Time Stamp (64 bit)
136-143
IN 6 Off-On Time Stamp (64 bit)
144-151
IN 6 On-Off Time Stamp (64 bit)
152-159
IN 7 Off-On Time Stamp (64 bit)
160-167
IN 7 On-Off Time Stamp (64 bit)
168-175
IN 8 Off-On Time Stamp (64 bit)
176-183
IN 8 On-Off Time Stamp (64 bit)
184-191
IN 9 Off-On Time Stamp (64 bit)
192-199
IN 9 On-Off Time Stamp (64 bit)
200-207
IN 10 Off-On Time Stamp (64 bit)
208-215
IN 10 On-Off Time Stamp (64 bit)
216-223
IN 11 Off-On Time Stamp (64 bit)
224-231
IN 11 On-Off Time Stamp (64 bit)
232-239
IN 12 Off-On Time Stamp (64 bit)
240-247
IN 12 On-Off Time Stamp (64 bit)
248-255
IN 13 Off-On Time Stamp (64 bit)
256-263
IN 13 On-Off Time Stamp (64 bit)
264-271
IN 14 Off-On Time Stamp (64 bit)
Produced Assembly Instance 118
