Publication 1732E-UM002A-EN-P - March 2010
70 Interpret Status Indicators
Chapter Summary and
What’s Next In this chapter, you read how to interpret the Status Indicators on the module.
The next chapter describes how to troubleshoot the module using
RSLogix 5000.
Network status Off The device is not initialized or the module does not
have an IP address.
Flashing green The device has an IP address, but no CIP
connections are established.
Green The device is online, has an IP address, and CIP
connections are established.
Flashing red One or more connections have timed out.
Red The module has detected that its IP address is
already in use.
Network link
status Off No link established.
Green Link established on indicated port at 100 Mbps.
Flashing green Link activity present on indicated port at 100 Mbps.
Yellow Link established on indicated port at 10 Mbps.
Flashing yellow Link activity present on indicated port at 10 Mbps.
Auxiliary status Off No power to device or input not valid.
Green Power applied to device.
Digital input
status Off No valid input.
Yellow Valid input.
Red Sensor source voltage shorted.
Flashing red Sensor source open wire.
IMPORTANT
The Module Status Indicator will flash red and green for a
maximum of 30 seconds while the module completes its POST
(Power-On Self Test).
Indicator Status for Module
Status Description
