ArmorBlock 2 Port Ethernet
Module Specifications
Specifications
ArmorBlock 2 Port Ethernet Module Input Specifications – 1732E-IB16M12SOEDR
Attributes Value
Number of inputs 16
Input type Sink, 24V DC
Voltage, off-state input, max 5V DC
Voltage, on-state input, max 30V DC
Voltage, on-state input, nom 24V DC
Voltage, on-state input, min 11V DC
Current, off-state input, max 1.5 mA @ 5V DC
Current, on-state input, max 5 mA @ 30V DC
Voltage, sensor source, max 30V DC
Voltage, sensor source, min 10V DC
Input delay time
ON to OFF
OFF to ON
0…16000
μ
s
Isolation voltage 50V (continuous), Basic Insulation Type, Inputs and Sensor
Power to Network
No isolation between individual Inputs or between
Network channels Type tested at 707V DC for 60s
Voltage, auxiliary power, max 30V DC
Voltage, auxiliary power, min 12V DC
Current, Ethernet system
power, max
(pins 2, 3 sensor
source/module power) 1.2 A
Current, sensor source, per
input, max 50 mA
Current, sensor source, per
connector, max 100 mA
Timestamp accuracy 100
μ
s
Refer to the module input delay tables on page 68 .
Communication rate EtherNet/IP
10/100 Mbps
Full or half-duplex
100 meter per segment
