80 Module Tags
I.PtXX_YYShortCircuit
BOOL
Per point
XX = even numbered input 0…14
YY = odd numbered input 1…15
A Short Circuit condition exists per I/O connector. For example, 00_01 or 14_15
0 = no fault
1 = short circuit
For more information on Short Circuit Protection, see
.
I.NewData
INT
Per point
(1)
Flag indicating if new timestamp data was detected on the input.
0 = no new timestamp data on the input
1 = new timestamp data on the input (since last acknowledged)
Because input data for all inputs is sent the next RPI after each timestamped
transition, this tag is useful to quickly determine on which input the transition
occurred. For example, if the module sends new input data to the
owner-controller and I.NewData.5 = 1, you know that at least one of the
timestamps for input 5 (I.Timestamp[5].OffOn or I.Timestamp[5].OnOff) has new
data.
This tag only clears when the controller acknowledges the new data or all
events on the module are reset. For more information, see
I.EventOverflow
INT
Per point
Set for an input when the module either:
•
Does not timestamp a transition on the input – The module has
Timestamp Latch enabled and a similar transition has already been
timestamped on this input but has not been cleared via the O.EventAck
and O.NewDataAck output tags (see page 64).
or
•
Overwrites previously-recorded timestamp data for the input – The
module has Timestamp Latch disabled and multiple transitions occur on
the input. In this case, timestamp data from new transitions are
recorded before previously-recorded transitions were cleared from the
input via the O.EventAck and O.NewDataAck output tags (see
This value is cleared if the module is reset.
I.EventNumber.x
DINT
Modulewide
Running count of the timestamped transitions; this tag increments by one with
each new transition that the module timestamps and rolls over to 1, not 0.
This value is cleared if the module is reset.
I.LocalClockOffset
DINT[2]
Modulewide
The offset from the local clock to the system time. This value is useful for
detecting steps in time.
This value updates when a PTP update is received.
Input Tags
Tag Name
Type
Set on Per
Point or
Modulewide
basis
Description
