74 ArmorBlock 2 Port Ethernet Module Specifications
CIP Sync (PTP) clock
Transparent clock, and slave only ordinary clock
Status indicators
Module Status - red/green
Network Status - red/green
Link Status - green/yellow
Auxiliary Power - green
I/O Status - yellow/red
Dimensions (HxWxD), approx.
179 x 65 x 43.25 mm (7.05 x 2.56 x 1.70 in.)
Weight, approx.
0.34 kg (0.75 lb)
Enclosure type rating
Meets IP65/66/67/69K (when marked)
Wiring category
(1)
1 - on signal ports
1 - on power ports
1 - on communications ports
(1)
Use this Conductor Category information for planning conductor routing. Refer to publication
,
Industrial Automation Wiring and Grounding Guidelines.
Environmental Specifications
Attribute
Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…60 °C (-4…140 °F)
Temperature, storage
IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Non-operating
Thermal Shock):
-40…85 °C (-40…185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% non-condensing
Vibration
IEC60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
Shock, operating
IEC60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Shock, non-operating
IEC60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Emissions
CISPR 11:
Group 1, Class A
ESD immunity
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM @ 900 Mhz
10V/m with 200 Hz 50% Pulse 100% AM @ 1890 Mhz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
ArmorBlock 2 Port Ethernet Module Input Specifications – 1732E-IB16M12SOEDR
Attributes
Value
