Monitoring Status Data
Chapter 7
7-22
Word Description
Bits
62
6
LoopĆ7 Low Deviation Alarm Ċ (set in word 19 of the configuration block)
•
0 = LoopĆ7 PV input is above the low deviation alarm value.
•
1 = LoopĆ7 PV input is at or below the low deviation alarm value.
7
LoopĆ8 Low Deviation Alarm Ċ (set in word 19 of the configuration block)
•
0 = LoopĆ8 PV input is above the low deviation alarm value.
•
1 = LoopĆ8 PV input is at or below the low deviation alarm value.
8
LoopĆ1 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ1 PV input is below the high deviation alarm value.
•
1 = LoopĆ1 PV input is at or above the high deviation alarm value.
9
LoopĆ2 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ2 PV input is below the high deviation alarm value.
•
1 = LoopĆ2 PV input is at or above the high deviation alarm value.
10
LoopĆ3 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ3 PV input is below the high deviation alarm value.
•
1 = LoopĆ3 PV input is at or above the high deviation alarm value.
11
LoopĆ4 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ4 PV input is below the high deviation alarm value.
•
1 = LoopĆ4 PV input is at or above the high deviation alarm value.
12
LoopĆ5 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ5 PV input is below the high deviation alarm value.
•
1 = LoopĆ5 PV input is at or above the high deviation alarm value.
13
LoopĆ6 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ6 PV input is below the high deviation alarm value.
•
1 = LoopĆ6 PV input is at or above the high deviation alarm value.
14
LoopĆ7 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ7 PV input is below the high deviation alarm value.
•
1 = LoopĆ7 PV input is at or above the high deviation alarm value.
15
LoopĆ8 High Deviation Alarm Ċ (set in word 20 of the configuration block)
•
0 = LoopĆ8 PV input is below the high deviation alarm value.
•
1 = LoopĆ8 PV input is at or above the high deviation alarm value.
