Chapter 7
Monitoring Status Data
7-19
Word Description
Bits
57
0-15
LoopĆ7 PID Error Value Ċ (-3276.7
thru +3276.7
)
58
0-15
LoopĆ8 PID Error Value Ċ (-3276.7
thru +3276.7
)
59
0-15
ColdĆJunctionĆCompensation Temperature Ċ (0
C thru +70.0
C)
60
0
ColdĆJunctionĆCompensation Temperature Low Alarm Ċ (0
C thru +70
C)
•
0 = ColdĆjunctionĆcompensation temperature is 0
C or above.
•
1 = ColdĆjunctionĆcompensation temperature is below 0
C.
1
ColdĆJunctionĆCompensation Temperature High Alarm Ċ (0
C thru +70
C)
•
0 = ColdĆjunctionĆcompensation temperature is 70
C or below.
•
1 = ColdĆjunctionĆcompensation temperature is above 70
C.
2
AutoĆTuning in Progress Ċ (controlled by bit 1 of word 34 of the dynamic block)
•
0 = AutoĆtuning not in progress
•
1 = AutoĆtuning in progress
3-15
Reserved.
61
0
LoopĆ1 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ1 PV input is above the low temperature alarm value.
•
1 = LoopĆ1 PV input is at or below the low temperature alarm value.
1
LoopĆ2 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ2 PV input is above the low temperature alarm value.
•
1 = LoopĆ2 PV input is at or below the low temperature alarm value.
2
LoopĆ3 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ3 PV input is above the low temperature alarm value.
•
1 = LoopĆ3 PV input is at or below the low temperature alarm value.
3
LoopĆ4 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ4 PV input is above the low temperature alarm value.
•
1 = LoopĆ4 PV input is at or below the low temperature alarm value.
4
LoopĆ5 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ5 PV input is above the low temperature alarm value.
•
1 = LoopĆ5 PV input is at or below the low temperature alarm value.
5
LoopĆ6 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ6 PV input is above the low temperature alarm value.
•
1 = LoopĆ6 PV input is at or below the low temperature alarm value.
6
LoopĆ7 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ7 PV input is above the low temperature alarm value.
•
1 = LoopĆ7 PV input is at or below the low temperature alarm value.
7
LoopĆ8 Input Low Temperature Alarm Ċ (set in word 17 of the configuration block)
•
0 = LoopĆ8 PV input is above the low temperature alarm value.
•
1 = LoopĆ8 PV input is at or below the low temperature alarm value.
