Rockwell Automation 1771-TCM,D17716.5.108 TEMPERATURE CONTROL MOD User Manual
Page 47

Operating the Module
Chapter 6
6-4
Word Description
Bits
12
0-15
LoopĆ3 Run Temperature SetĆpoint Value Ċ Used when bit 2 of word 1
0
is on (0 thru 999.9
).
13
0-15
LoopĆ3 Manual Output Value (CV) Ċ Used when bit 1 of word 10 is off (-100.00 thru +100.00).
14
0
LoopĆ4 Enable
•
0 = Loop 4 disabled.
•
1 = Loop 4 enabled if PID control mode selected (bits 7-8, word 2, config block).
1
LoopĆ4 Auto/Manual Mode Select
•
0 = Loop 4 is in the manual mode Ċ the manual output value (from word 17) is used as the CV value.
•
1 = Loop 4 is in the automatic mode Ċ the PID algorithm generates the CV value.
2
LoopĆ4 SetĆPoint Select
•
0 = Select the standbyĆtemperature setĆpoint value from word 15.
•
1 = Select the runĆtemperature setĆpoint value from word 16.
3
LoopĆ4 AutoĆTuning Enable
•
0 = Disable autoĆtuning.
•
1 = Enable autoĆtuning Ċ autoĆtuning can be invoked by an offĆtoĆon transition of bit 1 of word 34.
4
Always = 0.
5
LoopĆ4 PID Integral Term Reset Enable
•
0 = Accumulate PID integral term.
•
1 = Reset the PID integral term on the 0ĆtoĆ1 transition, and then allow accumulation until the next 0ĆtoĆ1 transition.
6-15
Always = 0.
15
0-15
LoopĆ4 Standby Temperature SetĆpoint Value Ċ Used when bit 2 of word 14 is off (0 thru 999.9
).
16
0-15
LoopĆ4 Run Temperature SetĆpoint Value Ċ Used when bit 2 of word 14 is on (0 thru 999.9
).
17
0-15
LoopĆ4 Manual Output Value (CV) Ċ Used when bit 1 of word 14 is off (-100.00 thru +100.00).
