Using This Manual P–4
Publication 1771-6.5.124 – August 1997
The 1771-ACN15 and 1771-ACNR15 adapter modules are two of
many hardware components that make up a programmable controller
system. The table below lists the hardware components and products
with which you can use the adapter module.
Compatible Hardware Products
Product name Description Catalog number
Processors PLC–5/20C15, PLC-5/40C15 and PLC-5/80C15 processors 1785-L20C15, 1785-L40C15,
L80C15
Communication
Devices ControlNet KTCx Communication Card
ControlNet Serial/Parallel Communication Interface
Flex I/O ControlNet Adapter
1771 ControlNet Adapter Module 1784-KTC15x
1770-KFC
1794-ACN15, ACNR15
1771-ACN15, -ACNR15
Universal I/O
Chassis 4–slot
8–slot
12–slot
16–slot 1771–A1, –A1B
1771–A2, –A2B
1771–A3B, A3B1
1771–A4, –A4B
I/O Modules Block transfer modules
8–point I/O Standard density I/O modules
16–point I/O High density I/O modules
32–point I/O Quad–Density I/O modules All modules that use the 1771
I/O structure
Power Supplies System power supply
Auxiliary power Supply
Auxiliary Power Supply module (120V ac input, 3A)
Auxiliary Power Supply module (120V ac input, 8A)
Redundant Power Supply module
Auxiliary Power Supply module (24V dc input, 8A)
Auxiliary Power Supply module (220/240V ac input, 8A)
Auxiliary Power Supply module (120/220V ac input, 16A)
PLC–2 Power Supply (115V ac input)
PLC–2 Power Supply (24V dc input)
Local Power Supply
Auxiliary Power Supply (24V dc input) 1771–P1
1771–P2
1771–P3
1771–P4, –P4S, –P4S1
1771–P4R
1771–P5
1771–P6S, –P6S1
1771–PS7
1772–P1
1772–P4
1774–P1
1777–P4
Product Compatibility
