Appendix
A
Publication 1771-6.5.124 – August 1997
Specifications
Module Location
1771 I/O chassis, leftmost slot
Interconnect Cable
Quad shield RG-6 coaxial cable – Refer to the
ControlNet Cable System manual (pub. no.
1786-6.2.1) for more information
Power Dissipation
5 Watts
Thermal Dissipation
17.06 BTU/hr
Backplane Current
1.0A @ 5V
Keying
Upper connector: between 54 and 56
Lower connector: between 16 and 18
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
0
o
to 60
o
C (32
o
to 140
o
F)
–40
o
to 85
o
C (–40
o
to 185
o
F)
5% to 95% (without condensation)
