3–5 Addressing Modes for Your I/O
Publication 1771-6.5.124 – August 1997
Figure 3.4
8-point Input and Output Modules Using Eight Bits of the Input
Image Table Word and Eight Bits of the Output Image Table Word
In p u t
T e rm in a ls
0 0
0 1
0 2
0 3
0 4
0 5
0 6
0 7
O u tp u t
T e rm in a ls
1 0
1 1
1 2
1 3
1 4
1 5
1 6
1 7
1 7 1 6 1 5 14 12 1 0 0 7 0 6 05 03 0 2 0 1 0 0 0 4 1 1 1 3
O u tp u t im a g e ta b le w o rd co rre sp o n d in g to th e I/O g ro u p .
un u se d
1 7 1 6 1 5 14 12 1 0 0 7 0 6 05 03 0 2 0 1 0 0 0 4 1 1 1 3
In p u t im a g e ta b le w o rd co rre sp o n d in g to th e I/O g ro u p .
1 49 65
O u tp ut b its u se d
In p ut b its u se d A lw a ys 0
2-slot I/O Group
