3. Module I/O
Inputs
The module has two independent channels that you configure to process
signals from machine sensors (default) or from the SLC output image table
across the backplane. Types of machine sensors include::
Outputs (Summary Data)
The module processes a frame of summary data for each molding cycle,
and alternately makes available the previous frame for display. It does this
for channels 1 and 2. Your ladder logic can read summary data from the
module’s M0/M1 files. You can observe summary data displayed on a PC
equipped with DARTWin software. The PC must be linked to the module
with DARTNet network from RJG Technologies, Inc.
A list of summary data follows. For a complete list with word addresses,
see the M0/M1 File Listing in section 11.
level: range application:
low
2mV/V sensitivity mold pressure
4-20mA general purpose
-100 to +100mV bi-directional
high 0-10V hydraulic pressure
Summary Data Displayed on Your PC and Read by SLC in M0/M1 Files
injection cycle time
peak injection pressure
minimum cycle pressure
time to peak pressure
trigger time (off to on to off) for T1 (injection forward - fill, pack, and hold)
trigger time (off to on to off) for T2 (fill)
trigger time (off to on to off) for T3 (screw backup)
trigger time (off to on to off) for T4 (mold closed)
integral to peak pressure in units of PSIxSec
integral of trigger 1 (injection forward) in units of PSIxSec
integral of trigger 2 (fill) in units of PSIsec
integral of trigger 3 (screw backup) in units of PSIxSec
integral of trigger 4 (mold closed) in units of PSIxSec
integral of injection cycle in units of PSIxSec
