16 Mold Pressure Module
Publication 1746-5.13 July 1998
11. Listing of M0/M1 file words
You load M0/M1 file data into the module from your PC equipped with
DARTwin software. M0 and M1 files contain:
• module configuration data, loaded by DARTWin software (words 0-48)
• summary data processed by the module (words 49-106)
Summary data (in units of A/D counts x 1/100 sec.) is stored in two frames:
frame 1 = words 49-75
frame 2 = words 76-106
Important: See summary data notes on page 18.
Address (e = module slot number) Description
Module Config Data
Channel 1 (M0)
Channel 2 (M1)
M0:e.0, 2, 4, 6 M1:e.0, 2, 4, 6 Dead time, trigger ON (for triggers 1, 2, 3, 4)
M0:e.1, 3, 5, 7 M1:e.1, 3, 5, 7 Dead time, trigger OFF (for triggers 1, 2, 3, 4)
M0:e.8 M1:e.8 Alarm control word (enable/disable)
M0:e.9 M1:e.9 Alarm level, cycle time low
M0:e.10 M1:e.10 Alarm level, cycle time high
M0:e.11 M1:e.11 Alarm level, peak high
M0:e.12 M1:e.12 Alarm level, peak low
M0:e.13 M1:e.13 Alarm level, peak time high
M0:e.14 M1:e.14 Alarm level, peak time low
M0:e.15, 17, 19, 21 M1:e.15, 17, 19, 21 Alarm level, trigger time low (triggers 1, 2, 3, 4)
M0:e.16, 18, 20, 22 M1:e.16, 18, 20, 22 Alarm level, trigger time high (triggers 1, 2, 3, 4)
M0:e.23 M1:e.23 Alarm level, minimum in frame, low
M0:e.24 M1:e.24 Alarm level, minimum in frame, high
M0:e.25, 26 M1:e.25, 26 Alarm level, peak integral low
M0:e.27, 28 M1:e.27, 28 Alarm level, peak integral high
M0:e.29, 30 M1:e.29, 30 Alarm level, trigger 1 integral low
M0:e.31, 32 M1:e.31, 32 Alarm level, trigger 1 integral high
M0:e.33, 34 M1:e.33, 34 Alarm level, trigger 2 integral low
M0:e.35, 36 M1:e.35, 36 Alarm level, trigger 2 integral high
M0:e.37, 38 M1:e.37, 38 Alarm level, trigger 3 integral low
M0:e.39, 40 M1:e.39, 40 Alarm level, trigger 3 integral high
M0:e.41, 42 M1:e.41, 42 Alarm level, trigger 4 integral low
M0:e.43, 44 M1:e.43, 44 Alarm level, trigger 4 integral high
M0:e.45, 46 M1:e.45, 46 Alarm level, frame integral low
M0:e.47, 48 M1:e.47, 48 Alarm level, frame integral high
