Wiring
Chapter 6
6-7
Terminal Block TB1 -
5Ć52ĂAmp Power Wiring (cont.)
Power Drive Maximum
Rating Output Wire Wire Maximum
Code Current Group n Size C Torque c
003 5 Amps 2 6 AWG 20 In-lbs
005 8 Amps 2 6 AWG 20 In-lbs
007 11 Amps 2 6 AWG 20 In-lbs
010 14 Amps 2 6 AWG 20 In-lbs
015 21 Amps 2 6 AWG 20 In-lbs
020 27 Amps 2 6 AWG 20 In-lbs
025 34 Amps 2 6 AWG 20 In-lbs
030 40 Amps 2 6 AWG 20 In-lbs
040 52 Amps 2 6 AWG 20 In-lbs
n Wire group number chart, page 6-3.
C 16 mm 2 .
c 2.26 N-m.
Maximum Wire Size and Torque Requirements
Use the following guidelines when selecting branch circuit protection.
5 Amp Drive Fuse Size 10A Fuse Type KTK-R, JJS or Equivalent
8 Amp Drive Fuse Size 15A Fuse Type KTK-R, JJS or Equivalent
11 Amp Drive Fuse Size 20A Fuse Type KTK-R, JJS or Equivalent
14 Amp Drive Fuse Size 25A Fuse Type A4J, JJS or Equivalent
21 Amp Drive Fuse Size - A Fuse Type A4J -30, JJS -35 or Equivalent
27 Amp Drive Fuse Size 45A Fuse Type A4J, JJS or Equivalent
34 Amp Drive Fuse Size 60A Fuse Type A4J, JJS or Equivalent
40 Amp Drive Fuse Size - A Fuse Type A4J -60, JJS -70 or Equivalent
52 Amp Drive Fuse Size 80A Fuse Type A4J, JJS or Equivalent
