Installation
Chapter 5
5-4
Dimensions, Weights and Conduit Entry Locations
1336VT 40Ć52 Amp
Open Chassis (IP00) and NEMA Type 1 (IP20) Enclosures
Nominal Dimensions and Weights
in Inches (Millimeters) and Pounds (Kilograms)
A B C D E F G H I J K L M Weight
14.32 23.59 9.27 11.70 22.41 1.31 0.59 6.64 2.63 — — — — 47.3
(364) (599) (235) (297) (570) (33.3) (15) (159) (67) (21.5)
14.32 23.59 9.27 11.70 22.41 1.31 0.59 6.64 2.63 4.38 4.19 1.88 2.62 54.3
(364) (599) (235) (297) (570) (33.3) (15) (159) (67) (111) (106) (48) (7) (24.6)
Open
Chassis
NEMA
Type 1
J
K
(NEMA Type 1 –– Bottom)
L M M
➌
➋
➍
I H
C
(NEMA Type 1 –– Side)
PR
Enter
Freq
PR
Jog
Stop
Start
(NEMA Type 1 –– Front)
D F
A
F
E
B
➊
Mounting Holes –– 0.312" (7.92mm) Diameter
➋
Conduit Entry –– 0.50" (13.0 mm) Diameter
➌ Conduit Entry –– 1.00" (25.4 mm) Diameter and 1.25" (32.0 mm) Diameter
➍ 1336-MOD-S1 Serial Port Connector Cover Plate
G
➊
