7–7

Display and Keypad Operation

Publication 1302-5.0 — January, 1998

Displaying the Percent Selected Speed Reference

To display the percent selected speed reference, parameter F-13 must
be set to ON. Use the following procedure to display the percent
selected speed reference:

Step 1. Stop the Drive (if it is running) by pressing the

STOP

RESET

key.

Step 2. Enter program mode by pressing the

Mode
Enter

key until the

PROGRAM LED turns on.

Step 3. Press the

key until F-13 is displayed.

Step 4..

Press the

Mode
Enter

key to access the parameter.

Step 5.. Press the

key until ON is displayed.

Step 6.. Press the

Mode
Enter

key to save the value. (F-13 will be

displayed.)

Step 7.. Press the

STOP

RESET

key to exit program mode.

Step 8.. Start the Drive by pressing the

START

key.

Step 9.. Press the

Mode
Enter

key until all three monitor mode LEDs are

on.

The display will show the active speed reference as 1 to 100% of
maximum speed (F-04).

Scaling the RPM Display and Reference Using F–08

The RPM display and reference can be scaled to an engineering unit
to match your application. Refer to the F-08 description in Chapter 8
for this procedure.
