5–8 Drive Wiring
Publication 1302-5.0 — January, 1998
!
ATTENTION: The 1302 control circuitry includes
solid state components. You must provide an
additional hardwired stop circuit to remove AC line
power to the Drive in the case of improper operation.
Failure to provide a hardwired emergency stop could
result in equipment damage, bodily injury or death.
When AC input power is removed, there will be a loss
of inherent regenerative braking effect and the motor
will coast to a stop. An auxiliary braking method may
also be required depending on the application.
Snubber Resistor Wiring
Snubber resistor wiring connects to terminals 12 and 13 on the
Regulator board’s terminal strip. See Figure 5.9.
Drive Model Number
Snubber
Resistor
Terminals
Control Terminal
Strip Connections
Power Terminal
Strip Connections
1302 - CXXX 1 (+)
2 (ć)
147 (+)
45 (ć)
13 (+)
14 (ć)
12
13
N/A
N/A
N/A
(+) DC Bus
(ć) DC Bus
(+) 10V
(ć) 10 COM
