Page 12
2–6
1302 AC Drive Description
Publication 1302-5.0 — January, 1998
A model number identifies each 1302 AC Drive as detailed in Table
2.A. This number appears on the shipping label and on the Drive’s
nameplate located on the right side of the Drive housing. The
Drive’s model number contains codes that indicate: input voltage
range, enclosure rating, and horsepower rating. Drive enclosure
ratings are detailed later in this chapter. All 1302 Drives described
in this instruction manual function in the same manner.
Table 2.A - Power and NEMA Enclosure Ratings
Model Number
Input Voltage
Horsepower
Enclosure
Size
NEMA
Rating
Input
Amps
Input
KVA
Output
Amps*
Power
Loss
Watts**
1302–C001–AA
575 VAC
1
B
1
2.0
2.0
1.6
50
1302–C001–AF
575 VAC
1
B
4X/12
2.0
2.0
1.6
50
1302–C002–AA
575 VAC
2
B
1
3.4
3.3
2.7
90
1302–C002–AF
575 VAC
2
B
4X/12
3.4
3.3
2.7
90
1302–C003–AA
575 VAC
3
B
1
5.2
5.1
4.3
120
1302–C003–AF
575 VAC
3
B
4X/12
5.2
5.1
4.3
120
1302–C005–AA
575 VAC
5
B
1
7.5
7.5
6.2
150
1302–C005–AF
575 VAC
5
B
4X/12
7.5
7.5
6.2
150
1302–C007–AA
575 VAC
7.5
C
1
10.9
10.9
9.0
180
1302–C007–AF
575 VAC
7.5
C
4X/12
10.9
10.9
9.0
180
1302–C010–AA
575 VAC
10
C
1
14.5
14.4
12.0
250
1302–C010–AF
575 VAC
10
C
4X/12
14.5
14.4
12.0
250
*
To properly size the drive for motor nameplate horsepower and amps, refer to Chapter 3 for more information.
**
Full load at all carrier frequencies. Refer to Chapter 3 for more information.
