Classic-Craft
Door Panel
Dimensions
3.8 2014 (BOOK SIZE) Comp 3
6/8 Classic-Craft Canvas Doors
NOTE: 3/0 only.
C
35-15/16”
A
D
79-1/4”
B
17-33/64”
7-25/32”
LITE
DESCRIPTION
A B C D E
27-3/32”
27-1/16”
NOTE: 3/0 only.
4-39/64”
35-15/16”
27-1/16”
44-1/16”
79-1/4”
4-27/64”
17-33/64”
7-25/32”
E
5-9/32”
26-7/32” 4-55/64”
TYP.
26-7/32” 4-55/64”
TYP.
Wrought Iron Only
4-1/64”
TYP.
4-1/64”
TYP.
T
NON
WROUGHT
IRON
WROUGHT
IRON
4-27/64”
4-7/16”
4-37/64”
4-41/64”
44-3/32”
44-1/16”
5-9/32”
5-1/4”
2/3 Arch Lite 1 Panel Plank
(2542A-1W)
(Slab-CCV205NR)
2/3 Lite 1 Panel Plank
(2542, 2542-1W)
(Slab-CCV205NR)
Daylight Opening: 24" x 41"
(965 sq.in.)
Daylight Opening:
(Wrought Iron)
24-1/16" x 41-1/16"
(988 sq.in.)
Daylight Opening:
(Non Wrought Iron)
24-3/32" x 41-3/32"
(991 sq.in.)
