Therma-Tru COMP 3 Classic-Craft Door Panel Dimensions - Book Size - Manual (Page 13)

Classic-Craft
Door Panel
Dimensions
Comp 3 2014 (BOOK SIZE) 3.13
6/8 Classic-Craft Canvas Doors
4-57/64”
10-1/64” TYP.
79-1/4”
8-23/32”
35-15/16”
3-57/64” TYP.
C
79-1/4”
8-23/32”
35-15/16”
A B
D
10-1/64”
E
A B C D E
27-17/32” 4-13/64” 4-13/64 53-1/32” 3-9/32”
27-1/2” 4-7/32” 4-7/32” 53” 3-19/64”
NOTE: 3/0 only.
NOTE: 3/0 only.
26-7/32” 4-55/64”
TYP.
26-7/32” 4-55/64”
TYP.
3/4 Lite 1 Panel
(2551, 2551-1W)
(Slab-CCV050, CCV200)
5 Panel
(Slab-CCV050)
(Impact-CCV050H)
LITE
DESCRIPTION
NON
WROUGHT
IRON
WROUGHT
IRON
Daylight Opening:
(Wrought Iron)
24-1/2" x 50"
(1225 sq.in.)
Daylight Opening:
(Non Wrought Iron)
24-17/32" x 50-1/32"
(1228 sq.in.)
