Classic-Craft
Door Panel
Dimensions
3.18 2014 (BOOK SIZE) Comp 3
8/0 Classic-Craft Canvas Doors
4-7/8"
26-7/32"
B
A
35-15/16"
C
D
10"
8-13/16"
95-1/4"
8' 3/4 Lite 1 Panel
(2566, 2566-1W)
(Slab-CCV8030)
NOTE: 3/0 only.
LITE
DESCRIPTION
A B C D
NON
WROUGHT-
IRON
27-17/32" 4-3/16" 4-19/32" 68-9/32"
WROUGHT-
IRON
27-1/2" 4-7/32" 4-5/8" 68-1/4"
Daylight Opening:
(Wrought Iron)
24-1/2" x 65-1/4"
(1599 sq.in.)
Daylight Opening:
(Non Wrought Iron)
24-17/32" x 65-9/32"
(1602 sq.in.)
4-7/8"
35-15/16" 4-7/8"
52-1/32"
22-19/32"
8-13/16"
95-1/4"
8' 2 Panel Square Top
(Slab - CCV8220)
(Impact Slab - CCV8220H)
NOTE: 3/0 only.
26-7/32"
