Classic-Craft
Door Panel
Dimensions
3.16 2014 (BOOK SIZE) Comp 3
8/0 Classic-Craft Canvas Doors
26-7/32"
4-7/8"
11-1/4" 3-23/32"
35-15/16"
5-5/32"
10-13/32"
4-27/32"
35-7/32"
24-3/8"
8-13/16"
8' 6 Panel
(Slab-CCV8060)
(Impact-CCV8060H)
NOTE: 3/0 only.
95-1/4"
4-7/8"
11-1/4"
3-23/32"
26-7/32"
8-13/16"
24-3/8"
35-15/16"
95-1/4"
8' 2/3 Lite 2 Panel
(2551, 2551-1W)
(Slab-CCV8060)
NOTE: 3/0 only.
C
D
B A
LITE
DESCRIPTION A B C D
NON
WROUGHT-
IRON 27-17/32" 4-3/16" 4-7/16" 53-1/32"
WROUGHT-
IRON 27-1/2" 4-7/32" 4-15/32" 53"
Daylight Opening:
(Wrought Iron)
24-1/2" x 50"
(1225 sq.in.)
Daylight Opening:
(Non Wrought Iron)
24-17/32" x 50-1/32"
(1228 sq.in.)
