Classic-Craft
Door Panel
Dimensions
3.12 2014 (BOOK SIZE) Comp 3
6/8 Classic-Craft Canvas Doors
NOTE: 3/0 only.
NOTE: 3/0 only.
4-57/64”
43-9/16”
79-1/4”
4-9/16”
17-33/64”
8-23/32”
35-15/16”
C
D
79-1/4”
E
17-33/64”
8-23/32”
35-15/16”
A B
LITE
DESCRIPTION A B C D E
27-3/32” 4-27/64” 4-37/64” 44-3/32” 4-11/32”
WROUGHT-
IRON
27-1/16” 4-7/16” 4-41/64” 44-1/16” 4-5/16”
26-7/32” 4-55/64”
TYP.
26-7/32” 4-55/64”
TYP.
T
2/3 Lite 1 Panel
(2542, 2542-1W)
(Slab-CCV220)
2 Panel Square Top
(Slab-CCV220)
(Impact-CCV220H)
NON
WROUGHT-
IRON
Daylight Opening:
(Wrought Iron)
24-1/16" x 41-1/16"
(988 sq.in.)
Daylight Opening:
(Non Wrought Iron)
24-3/32" x 41-3/32"
(991 sq.in.)
