Page 7
Classic-Craft
Door Panel
Dimensions
Comp 3
2014 (BOOK SIZE)
3.7
6/8 Classic-Craft Canvas Doors
NOTE: 3/0 only.
NOTE: 3/0 only.
4-57/64”
35-15/16”
43-9/16”
79-1/4”
5-1/2”
17-33/64”
7-25/32”
R 28-57/64”
4-57/64”
35-15/16”
43-9/16”
79-1/4”
5-1/2”
17-33/64”
7-25/32”
4-1/64”
TYP.
26-7/32”
4-55/64”
TYP.
26-7/32”
4-55/64”
TYP.
4-1/64”
TYP.
Arched 2 Panel Plank Soft Arch
(Slab-CCV205A)
(Impact-CCV205HA)
2 Panel Plank Soft Arch
(Slab-CCV205NR)
(Impact-CCV205H)
