Digital Video Recorder User Manual

42

4.9 P.T.Z Configuration

Enter into Main MenuSetupPTZ. P.T.Z configuration includes two submenus:

serial port and advanced.

4.9.1 Serial Port

Refer to Fig 4-42, enable P.T.Z control of any channel; select the correct PTZ settings

according to the external communication device, the meaning of PTZ parameters is

shown in the table below. Select

“all” and then do relevant setup, user can set all

channels with same parameters.

Fig 4-42 P.T.Z configuration-serial port

Click “Default” button to

r

estore the default setting; click “Apply” button to save the

setting; click “Exit” button to exit current menu.
