Steriflow Mark 94 Series User Manual
Page 4

MK94/0214/10K/AB
MK94 S
anitary
S
teaM
t
rapS
Model
Body
—
Size
—
End Connections
—
Special Options
94
C
075
C
K
Model/Body Joint
94C
Tri-Clamp Standard
O
rDering
s
cHematic
Size
075
3/4"
DN20
100
1"
DN25
150
1-1/2"
DN40
3
End Connections
Inlet
Outlet
C
Inch Tri-Clamp Vertical Inlet/Outlet
S
ISO Tri-Clamp Vertical Inlet/Outlet
D
DIN Tri-Clamp Vertical Inlet/Outlet
T
Inch Tube Vertical Inlet/Outlet
M**
DIN Tube Vertical Inlet/Outlet
P***
ISO TUbe Vertical Inlet/Outlet
Z
Non-Standard
C
H
C
H
Inch Tri-Clamp Horizontal Inlet/Outlet
C
H
C
V
Inch Tri-Clamp Horizontal Inlet/Vertical Outlet
C
V
C
H
Inch Tri-Clamp Vertical Inlet/Horizontal Outlet
4
Options
K
Bolted Clamp
S
Silverback Gasket TFE/SST Body Gasket,
USP Class VI
Z
Non-Standard
L
Electropolish
Note: You can combine up to two options in alphabetical
order.
For example: 94C-075-CHCH-LS
= MK94C with 3/4" Tri-clamp body, wingnut clamp,
horizontal inlet and outlet with electropolish body and
silverback gasket
Note: Note: if no gasket is specifically requested, a TFE/
Viton gasket is provided
Steriflow, a division of Jordan Valve
3170 Wasson Road • Cincinnati, OH 45209
513.533.5600 • 800.543.7311 • 513.871.0105 (f)
[email protected] • www.steriflowvalve.com
Steriflow Valve reserves the right to make revisions to its product, specifications, literature and related information without notice. Please visit our
website at www.steriflowvalve.com for the latest information on our products.
** According to DIN 1186, DIN 11850 row A
*** According to ISO DIN 1186 line B, ISO 1127
