Steriflow Mark 94 Series User Manual
Page 2

MK94 S
anitary
S
teaM
t
rapS
s
peciFicatiOns
Sizes:
3/4" (DN20), 1" (DN25), 1-1/2" (DN40)
End Connections
•
Standard – Sanitary clamp ends (Tri-Clamp)
•
Optional – Tube weld ends, DIN/ISO, threaded
Connection Orientation:
Vertical or horizontal
Material
•
Body Inlet/Outlet: ASTM A479 316L Stainless Steel
•
Thermal Element: 316L Stainless Steel
•
O-Ring-Gasket: Viton, Teflon Encapsulated (FDA,
USP Class VI approved)
•
Clamp: 304 SST
Maximum Operating Conditions
•
Maximum Operating Pressure (PMO): 50 psig
(3,5 bar)
•
Maximum Allowable Temperature (TMA): 350°F
(177°C)
Design Pressure/Temperature Rating
•
Maximum Allowable Pressure (PMA): 145 psig
(10,0 bar)
•
Maximum Allowable Temperature (TMA): 350°F
(177°C)
Maximum Recommended Differential Pressure
•
MK94: 5 – 50 psi (0,34 – 3,5 bar)
CRN Number:
CRN13987.5
Weight:
2.5 lbs (1,2 kgs)
D
imensiOns
- V
ertical
c
OnnectiOns
F
lOw
c
apacity
t
able
Condensate Temp
Below Saturation
(Subcooled Temp)
Capacity - lbs/hr (kg/hr) @ Differential
Pressure - psi (bar)
10
(0,69)
20
(1,38)
30
(2,07)
40
(2,76)
50
(3,45)
5°F
1355
(616)
1800
(818)
2460
(1118)
3050
(1386)
3410
(1550)
10°F
2190
(996)
3065
(1393)
3920
(1782)
4620
(2100)
5160
(2346)
20°F
3720
(1691)
5010
(2277)
5985
(2721)
7190
(3268)
7845
(3566)
Cold Water
5870
(2668)
8280
(3764)
10140
(4609)
11710
(5323)
13100
(5955)
3/4” (DN20) Size Inlet/Outlets
Condensate Temp
Below Saturation
(Subcooled Temp)
Capacity - lbs/hr (kg/hr) @ Differential
Pressure - psi (bar)
10
(0,69)
20
(1,38)
30
(2,07)
40
(2,76)
50
(3,45)
5°F
1490
(677)
1980
(900)
2705
(1230)
3355
(1525)
3750
(1705)
10°F
2410
(1096)
3370
(1532)
4310
(1959)
5080
(2309)
5675
(2580)
20°F
4090
(1859)
5510
(2505)
6585
(2993)
7910
(3596)
8630
(3923)
Cold Water
6460
(2936)
9110
(4141)
11550
(5250)
12800
(5818)
14410
(6550)
1” & 1-1/2” (DN25 & DN40) Size Inlet/Outlets
3.00
(76,2)
4.44
(112,8)
1.63
(41,8)
2.22
(56,4)
3.12
(79,2)
4.00
(101,6)
2.22
(56,4)
1.63
(41,8)
Bolted Clamp
Traditional Wingnut Clamp
