MK94 S

anitary

S

teaM

t

rapS

F

eatures

& b

eneFits

Choice of traditional or

bolted Tri-clamp standard

20 Ra (.5 Ra

µm

)

surface finish standard

Ball type tip helps insures low subcooling operation by

providing maximum flow with minimum lift. Helps insure

minimum condensate backup upstream of trap.

Drainable interior surface.

Proprietary fill and bellows

construction insures low

subcooling operation. Fast

reaction to temp change in-

sures minimum condensate

backup upstream of trap.

s

peciFicatiOn

Fully drainable, high capacity sanitary steam trap with body and plug components made from ASTM A479 316L.

Ball type stem tip pulls completely out of orifice flow path allowing full flow between 1355 #/hr of 5oF subcooled

condensate at SIP vessel maintenance temperature, to 14410 #/hr max cool water flow during SIP heat up.

4.37

(110,9)

2.00

(50,8)

5.68

(144,2)

Section A-A

A

A

D

imensiOns

- H

OrizOntal

c

OnnectiOns
