o
rDer
s
ChematiC
1
Model
96A
Standard
2
Size
100
1" (DN25)
150
1-1/2" (DN40)
200
2" (DN50)
3
Material
6L
316L Stainless Steel
4
Body & Cv
AH
20ra Interior/63rms Exterior (Standard); 4.5Cv
BH
20rA Interior/20ra Exterior; 4.5Cv
CH
8rA Interior/63rms Exterior; 4.5Cv
DH
20rA Interior/8ra Exterior; 4.5Cv
EH
8rA Interior/8ra Exterior; 4.5Cv
FH
8rA Interior/20ra Exterior; 4.5Cv
AM 20rA Interior/63rms Exterior (Standard); 10Cv
BM
20rA Interior/20ra Exterior; 10Cv
CM
8rA Interior/63rms Exterior; 10Cv
DM
20rA Interior/8ra Exterior; 10Cv
EM
8rA Interior/8ra Exterior; 10Cv
FM
8rA Interior/20ra Exterior; 10Cv
AN
20rA Interior/63rms Exterior (Standard); 19Cv
BN
20rA Interior/20ra Exterior; 19Cv
CN
8rA Interior/63rms Exterior; 19Cv
DN
20rA Interior/8ra Exterior; 19Cv
EN
8rA Interior/8ra Exterior; 19Cv
FN
8rA Interior/20ra Exterior; 19Cv
ZZ
Non-Standard
5
Trim; Cv & Seat
AJ
20 rA (Standard); Cv 4.5 Teflon Seats
BJ
8 rA; Cv 4.5 Teflon Seats
AQ
20 rA (Standard); Cv 10 Teflon Seats
BQ
8 rA; Cv 10 Teflon Seats
AT
20 rA (Standard); Cv 19 Teflon Seats
BT
8 rA; Cv 19 Teflon Seats
6
O-Ring
TY
Teflon Encaps. Viton / Jorlon Diaphragm
ZZ
Non-Standard
7
I/P or Loader Range
Type of Loader Max Load (psi)
00
None
AP
60 psi output I/P
AH
120 psi output I/P
BA
J Series 25 psi output
BC
J Series 50 psi output
BE
J Series 100 psi output
8
Diaphragm
JL
Jorlon
9
Actuator
AA
Anodized Aluminum
BA
316 Stainless Steel
1
—
2
—
3
4
5
6
7
8
9
10
Accessories
SC
Clean for oil free
XC
02 Clean
0F
PED Certification
