Instruction

Sheet

www

.prescolite.com

Prescolite T

ollFree T

echnical

Support

1.888.PRS.4TEC

• Hours: 8am - 5pm ET

Part No. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .06248600

Instruction

Sheet

INSTALLATION INSTRUCTIONS

79X TRIMS

TRIM INSTALLATION

ST832BB SERIES TRIMS:

1. ADJUST SOCKET BRACKET TO PROPER POSITION BY LOOSENING WING NUT.

PAR 30 LAMPS: SLIDE BRACKET TO LOWEST (TOWARDS APERTURE) POSITION.
PAR 38 LAMPS: SLIDE BRACKET TO HIGHEST (AWAY FROM APERTURE) POSITION.

2. TIGHTEN WING NUT SECURELY.
3. INSTALL TRIM BY LOCATING COIL SPRINGS IN SLOTS ON HOUSING.
4. INSTALL LAMP.

ST832 SERIES TRIMS:

1. ADJUST SOCKET BRACKET TO PROPER POSITION BY LOOSENING WING NUT.

PAR 30 LAMPS: SLIDE BRACKET TO LOWEST (TOWARDS APERTURE) POSITION.
PAR 38 LAMPS: SLIDE BRACKET TO HIGHEST (AWAY FROM APERTURE) POSITION.

2. TIGHTEN WING NUTSECURELY.
3. INSTALL LAMP.

4. ATTACH TRIM RETAINING CLIPS (3) TO HOUSING EQUALLY SPACED.

5. PRESS TRIM INTO APERTURE.

IMPORTANT SAFETY INFORMATION. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. Follow label information

and instructions concerning Wet or Damp Locations, installation near combustible materials, insulation, building materials,

and proper lamping. Do not install in areas subject to combustible vapors or gases. Before wiring to power supply and

during servicing or relamping, turn off power at fuse or circuit breaker. All servicing or relamping must be performed by

qualified service personnel. Product must be grounded to avoid potential electric shock or other potential hazard.

Product must be mounted in locations and at heights and in a manner consistent with its intended use, and in

compliance with the National Electrical Code and local codes. The use of accessory equipment not recommended by

the manufacturer or installed contrary to instructions may cause an unsafe condition. Do not block light emanating from

product in whole or part, as this may cause an unsafe condition. Do not allow items such as drapes, curtains, screens or

the like to come into contact with the product or to block light from the product, as this may cause an unsafe condition.

701 Millennium Boulevard • Greenville, SC 29607
With representatives offices in principal cities throughout North America.
Copyright 2008, 09/12 revision, All Rights Reserved - Printed in U.S.A.

CAUTION:

THIS PRODUCT CONTAINS CHEMICALS KNOWN TO THE STATE OF CALIFORNIA
TO CAUSE CANCER, BIRTH DEFECTS AND/OR OTHER REPRODUCTIVE HARM.
THOROUGHLY WASH HANDS AFTER INSTALLING, HANDLING, CLEANING, OR
OTHERWISE TOUCHING THIS PRODUCT.
