Physical data – Bryant LEGACY 569J User Manual
Page 6
6
PHYSICAL DATA
SINGLE CIRCUIT MODELS
569J*07
569J*08
569J*12
569J*14
569J*16
569J*25
Refrigeration System
# Circuits / # Comp. / Type
1 / 1 / Scroll
1 / 1 / Scroll
1 / 1 / Scroll
1 / 1 / Scroll
1 / 2 /Scroll
1 / 2 /Scroll
R ---410A charge A/B (lbs)
4.4
4.9
6.3
7.3
12.2
38.0
System charge w/ fan coil
8.4
10.2
13.8
18.0
24.6
38.0
Metering device
TXV
TXV
TXV
TXV
TXV
TXV
High---press. Trip / Reset (psig)
630 / 505
630 / 505
630 / 505
630 / 505
630 / 505
630 / 505
Low---press. Trip / Reset (psig)
54 / 117
54 / 117
54 / 117
54 / 117
54 / 117
54 / 117
Cond. Coil
Material (Fin/Tube)
Al/Al
Al/Al
Al/Al
Al/Al
Al/Al
Al/Cu
Coil type
Novation
Novation
Novation
Novation
Novation
RTPF
Rows / FPI
1 /
20.3
1 /
20.3
1 /
20.3
1 /
20.3
1 /
20.3
2 / 17
total face area (ft2)
17.5
20.5
25.0
31.8
25.0 x 2
25.0 x 2
Cond. fan / motor
Qty / Motor drive type
2 / direct
2 / direct
2 / direct
2 / direct
3 / direct
4 / direct
Motor HP / RPM
1/4 / 1100
1/4 / 1100
1/4 / 1100
1/4 / 1100
1/4 / 1100
1/4 / 1100
Fan diameter (in)
22
22
22
22
22
22
Nominal Airflow (cfm)
6,000
6,000
6,000
6,000
10,000
14,000
Watts (total)
610
610
610
610
970
1150
DUAL CIRCUIT MODELS
569J*12
569J*14
569J*16
569J*25
Refrigeration System
# Circuits / # Comp. / Type
2 / 2 /Scroll
2 / 2 /Scroll
2 / 2 /Scroll
2 / 2 /Scroll
R ---410A charge A/B (lbs)
3.0 /3.1
3.7/3.9
6.1/6.1
19.0/19.0
System charge w/ fan coil
7.4 / 7.4
10.8 / 10.8
12.0/12.0
19.0/19.0
Metering device
TXV
TXV
TXV
TXV
High---press. Trip / Reset (psig)
630 / 505
630 / 505
630 / 505
630 / 505
Low---press. Trip / Reset (psig)
54 / 117
54 / 117
54 / 117
54 / 117
Cond. Coil
Material (Fin/Tube)
Al/Al
Al/Al
Al/Al
Al/Cu
Coil type
Novation
Novation
Novation
RTPF
Rows / FPI
1 / 20.3
1 / 20.3
1 / 20.3
1 / 17
total face area (ft2)
25.0
31.8
25.0 x 2
25.0 x 2
Cond. fan / motor
Qty / Motor drive type
2 / direct
2 / direct
3 / direct
4 / direct
Motor HP / RPM
1/4 / 1100
1/4 / 1100
1/4 / 1100
1/4 / 1100
Fan diameter (in)
22
22
22
22
Nominal Airflow (cfm)
6,000
6,000
10,000
14,000
Watts (total)
610
610
970
1150
569J
