PERFORMANCE DATA (cont.)
569J*07A -- 524J*07 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
1800
Cfm
EA
(w
B
)
58
THC 65.8 65.8 74.1 63.4 63.4 71.4 60.7 60.7 68.3 58.3 58.3 65.7 54.7 54.7 61.6
SHC 57.4 65.8 74.1 55.3 63.4 71.4 53.0 60.7 68.3 50.9 58.3 65.7 47.8 54.7 61.6
62
THC 68.1 68.1 70.7 65.2 65.2 69.2 62.0 62.0 67.6 58.1 58.1 65.7 54.6 54.6 55.4
SHC 51.9 61.3 70.7 50.4 59.8 69.2 48.9 58.3 67.6 47.1 56.4 65.7 36.3 45.9 55.4
67
THC 74.0 74.0 74.0 70.9 70.9 70.9 67.3 67.3 67.3 63.4 63.4 63.4 56.7 56.7 56.7
SHC 42.3 51.8 61.3 41.0 50.5 59.9 39.5 49.0 58.4 37.9 47.3 56.8 35.3 44.9 54.4
72
THC 80.7 80.7 80.7 77.3 77.3 77.3 73.6 73.6 73.6 69.4 69.4 69.4 63.2 63.2 63.2
SHC 32.7 42.2 51.8 31.4 40.9 50.4 30.0 39.5 49.0 28.4 37.9 47.4 26.2 35.7 45.3
76
THC --- 86.2 86.2 --- 82.6 82.6 --- 78.6 78.6 --- 74.3 74.3 --- 70.7 70.7
SHC --- 34.5 44.3 --- 33.2 43.0 --- 31.8 41.6 --- 30.3 40.0 --- 29.0 38.7
2100
Cfm
EA
(w
B
)
58
THC 69.0 69.0 77.8 66.5 66.5 74.9 63.7 63.7 71.8 61.2 61.2 69.0 --- --- ---
SHC 60.3 69.0 77.8 58.0 66.5 74.9 55.6 63.7 71.8 53.5 61.2 69.0 --- --- ---
62
THC 70.2 70.2 77.1 67.2 67.2 75.5 64.0 64.0 73.6 60.4 60.4 70.7 --- --- ---
SHC 55.7 66.4 77.1 54.2 64.8 75.5 52.5 63.0 73.6 50.2 60.4 70.7 --- --- ---
67
THC 75.9 75.9 75.9 72.6 72.6 72.6 68.9 68.9 68.9 64.8 64.8 64.8 59.1 59.1 59.9
SHC 44.8 55.7 66.5 43.4 54.3 65.1 41.9 52.8 63.6 40.3 51.1 62.0 38.1 49.0 59.9
72
THC 82.5 82.5 82.5 79.0 79.0 79.0 75.2 75.2 75.2 70.9 70.9 70.9 63.9 63.9 63.9
SHC 33.7 44.6 55.5 32.4 43.3 54.2 31.0 41.8 52.7 29.4 40.3 51.1 26.9 37.9 48.8
76
THC --- 88.1 88.1 --- 84.3 84.3 --- 80.2 80.2 --- 75.5 75.5 --- 71.8 71.8
SHC --- 35.8 47.0 --- 34.5 45.6 --- 33.0 44.2 --- 31.4 42.5 --- 30.2 41.2
2400
Cfm
EA
(w
B
)
58
THC 71.7 71.7 80.8 69.0 69.0 77.8 66.1 66.1 74.5 62.6 62.6 70.6 58.9 58.9 66.3
SHC 62.6 71.7 80.8 60.3 69.0 77.8 57.7 66.1 74.5 54.7 62.6 70.6 51.4 58.9 66.3
62
THC 72.0 72.0 82.7 69.1 69.1 80.8 66.2 66.2 77.4 63.0 63.0 73.6 --- --- ---
SHC 59.0 70.9 82.7 57.4 69.1 80.8 55.0 66.2 77.4 52.3 63.0 73.6 --- --- ---
67
THC 77.3 77.3 77.3 74.0 74.0 74.0 70.2 70.2 70.2 66.1 66.1 66.9 62.5 62.5 65.0
SHC 47.1 59.3 71.5 45.7 57.9 70.1 44.2 56.4 68.6 42.6 54.7 66.9 41.0 53.0 65.0
72
THC 84.0 84.0 84.0 80.4 80.4 80.4 76.4 76.4 76.4 71.8 71.8 71.8 67.5 67.5 67.5
SHC 34.6 46.9 59.1 33.3 45.5 57.8 31.9 44.1 56.3 30.2 42.4 54.6 28.7 40.8 52.9
76
THC --- 89.5 89.5 --- 85.7 85.7 --- 81.4 81.4 --- 76.7 76.7 --- --- ---
SHC --- 36.9 49.4 --- 35.6 48.1 --- 34.2 46.6 --- 32.6 45.0 --- --- ---
2700
Cfm
EA
(w
B
)
58
THC 73.9 73.9 83.3 71.2 71.2 80.2 68.1 68.1 76.7 64.8 64.8 73.0 58.6 58.6 66.0
SHC 64.6 73.9 83.3 62.2 71.2 80.2 59.5 68.1 76.7 56.5 64.8 73.0 51.2 58.6 66.0
62
THC 74.0 74.0 86.5 71.3 71.3 83.3 68.2 68.2 79.7 64.8 64.8 75.8 --- --- ---
SHC 61.5 74.0 86.5 59.2 71.3 83.3 56.6 68.2 79.7 53.8 64.8 75.8 --- --- ---
67
THC 78.5 78.5 78.5 75.1 75.1 75.1 71.2 71.2 73.2 67.0 67.0 71.5 63.2 63.2 69.4
SHC 49.3 62.7 76.2 47.9 61.3 74.8 46.4 59.8 73.2 44.7 58.1 71.5 43.0 56.2 69.4
72
THC 85.1 85.1 85.1 81.4 81.4 81.4 77.3 77.3 77.3 72.6 72.6 72.6 65.3 65.3 65.3
SHC 35.5 49.0 62.5 34.2 47.6 61.1 32.7 46.1 59.6 31.1 44.5 57.9 28.6 42.2 55.7
76
THC --- 90.7 90.7 --- 86.7 86.7 --- 82.3 82.3 --- --- --- --- --- ---
SHC --- 38.1 51.8 --- 36.7 50.4 --- 35.3 48.9 --- --- --- --- --- ---
3000
Cfm
EA
(w
B
)
58
THC 75.9 75.9 85.5 73.0 73.0 82.3 69.8 69.8 78.7 66.3 66.3 74.7 62.4 62.4 70.4
SHC 66.3 75.9 85.5 63.8 73.0 82.3 61.0 69.8 78.7 57.9 66.3 74.7 54.5 62.4 70.4
62
THC 75.9 75.9 88.8 73.1 73.1 85.4 69.9 69.9 81.7 66.4 66.4 77.6 60.2 60.2 70.4
SHC 63.1 75.9 88.8 60.7 73.1 85.4 58.0 69.9 81.7 55.1 66.4 77.6 50.0 60.2 70.4
67
THC 79.5 79.5 80.7 76.0 76.0 79.3 72.1 72.1 77.6 67.9 67.9 75.7 63.7 63.7 73.5
SHC 51.4 66.0 80.7 49.9 64.6 79.3 48.4 63.0 77.6 46.7 61.2 75.7 44.8 59.2 73.5
72
THC 86.1 86.1 86.1 82.3 82.3 82.3 78.0 78.0 78.0 73.3 73.3 73.3 69.6 69.6 69.6
SHC 36.3 51.0 65.8 35.0 49.7 64.4 33.5 48.1 62.8 31.9 46.5 61.1 30.5 44.9 59.3
76
THC --- 91.6 91.6 --- 87.6 87.6 --- --- --- --- --- --- --- --- ---
SHC --- 39.1 54.0 --- 37.8 52.7 --- --- --- --- --- --- --- --- ---
--- Not operational
