PERFORMANCE DATA (cont.)
569J*16D -- 524J*25 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
6000
Cfm
EA
(w
B
)
58
THC 189.5 189.5 213.0 182.9 182.9 205.6 175.8 175.8 197.7 168.1 168.1 189.0 159.8 159.8 179.8
SHC 166.0 189.5 213.0 160.2 182.9 205.6 154.0 175.8 197.7 147.1 168.1 189.0 139.9 159.8 179.8
62
THC 191.7 191.7 215.9 184.0 184.0 211.1 176.3 176.3 203.9 168.3 168.3 196.3 159.8 159.8 186.5
SHC 155.8 185.8 215.9 151.6 181.3 211.1 146.0 174.9 203.9 140.1 168.2 196.3 133.1 159.8 186.5
67
THC 207.6 207.6 207.6 199.1 199.1 199.1 189.8 189.8 189.8 180.1 180.1 180.1 169.2 169.2 170.3
SHC 124.8 155.7 186.5 121.3 152.1 182.9 117.4 148.2 179.0 113.5 144.3 175.1 108.9 139.6 170.3
72
THC 225.6 225.6 225.6 216.6 216.6 216.6 206.8 206.8 206.8 196.1 196.1 196.1 184.7 184.7 184.7
SHC 92.7 123.8 154.8 89.3 120.4 151.4 85.7 116.7 147.7 81.8 112.7 143.7 77.6 108.5 139.5
76
THC --- 240.7 240.7 --- 231.2 231.2 --- 220.8 220.8 --- 209.6 209.6 --- --- ---
SHC --- 98.4 130.4 --- 95.2 127.1 --- 91.6 123.4 --- 87.8 119.4 --- --- ---
7000
Cfm
EA
(w
B
)
58
THC 197.6 197.6 222.2 190.6 190.6 214.3 183.0 183.0 205.9 174.8 174.8 196.7 165.9 165.9 186.6
SHC 173.0 197.6 222.2 166.8 190.6 214.3 160.1 183.0 205.9 152.9 174.8 196.7 145.2 165.9 186.6
62
THC 197.6 197.6 230.6 190.6 190.6 222.5 183.0 183.0 213.6 174.8 174.8 204.1 165.8 165.8 193.7
SHC 164.6 197.6 230.6 158.8 190.6 222.5 152.3 183.0 213.6 145.5 174.8 204.1 138.0 165.8 193.7
67
THC 211.7 211.7 211.7 202.9 202.9 202.9 193.4 193.4 195.5 183.1 183.1 191.2 172.1 172.1 186.3
SHC 132.4 167.8 203.3 128.7 164.1 199.6 124.8 160.2 195.5 120.6 155.9 191.2 116.0 151.2 186.3
72
THC 229.8 229.8 229.8 220.5 220.5 220.5 210.3 210.3 210.3 199.3 199.3 199.3 187.6 187.6 187.6
SHC 95.6 131.3 167.0 92.2 127.9 163.6 88.5 124.2 159.8 84.6 120.1 155.7 80.4 115.8 151.3
76
THC --- 245.1 245.1 --- 235.3 235.3 --- 224.5 224.5 --- --- --- --- --- ---
SHC --- 102.4 138.9 --- 99.1 135.5 --- 95.5 131.8 --- --- --- --- --- ---
8000
Cfm
EA
(w
B
)
58
THC 204.0 204.0 229.5 196.7 196.7 221.4 188.8 188.8 212.5 180.1 180.1 202.8 170.9 170.9 192.3
SHC 178.5 204.0 229.5 172.1 196.7 221.4 165.1 188.8 212.5 157.5 180.1 202.8 149.4 170.9 192.3
62
THC 204.0 204.0 238.2 196.6 196.6 229.7 188.7 188.7 220.5 180.2 180.2 210.5 170.8 170.8 199.6
SHC 169.8 204.0 238.2 163.6 196.6 229.7 157.0 188.7 220.5 149.8 180.2 210.5 142.0 170.8 199.6
67
THC 214.7 214.7 219.1 205.8 205.8 215.2 196.1 196.1 211.0 185.7 185.7 206.3 174.5 174.5 201.0
SHC 139.4 179.2 219.1 135.7 175.5 215.2 131.7 171.3 211.0 127.3 166.8 206.3 122.6 161.8 201.0
72
THC 232.9 232.9 232.9 223.4 223.4 223.4 213.0 213.0 213.0 201.7 201.7 201.7 189.2 189.2 189.2
SHC 98.4 138.6 178.8 94.9 135.1 175.3 91.2 131.3 171.4 87.2 127.2 167.3 82.8 122.8 162.7
76
THC --- 248.6 248.6 --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- 106.2 147.2 --- --- --- --- --- --- --- --- --- --- --- ---
9000
Cfm
EA
(w
B
)
58
THC 209.3 209.3 235.6 201.8 201.8 227.2 193.6 193.6 217.9 184.6 184.6 207.9 174.9 174.9 197.0
SHC 183.0 209.3 235.6 176.5 201.8 227.2 169.2 193.6 217.9 161.3 184.6 207.9 152.8 174.9 197.0
62
THC 209.3 209.3 244.5 201.7 201.7 235.7 193.5 193.5 226.2 184.6 184.6 215.8 174.9 174.9 204.5
SHC 174.1 209.3 244.5 167.8 201.7 235.7 160.9 193.5 226.2 153.4 184.6 215.8 145.3 174.9 204.5
67
THC 217.2 217.2 234.0 208.2 208.2 230.1 198.2 198.2 225.4 187.7 187.7 220.1 176.6 176.6 213.6
SHC 145.9 190.0 234.0 142.2 186.1 230.1 138.0 181.7 225.4 133.4 176.7 220.1 128.2 170.9 213.6
72
THC 235.4 235.4 235.4 225.7 225.7 225.7 215.1 215.1 215.1 203.7 203.7 203.7 191.4 191.4 191.4
SHC 100.9 145.5 190.0 97.5 142.0 186.5 93.7 138.1 182.6 89.7 134.0 178.3 85.4 129.6 173.7
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
10,
000
Cfm
EA
(w
B
)
58
THC 213.8 213.8 240.8 206.1 206.1 232.1 197.6 197.6 222.6 188.3 188.3 212.1 178.4 178.4 201.0
SHC 186.9 213.8 240.8 180.1 206.1 232.1 172.7 197.6 222.6 164.5 188.3 212.1 155.8 178.4 201.0
62
THC 213.8 213.8 249.9 206.0 206.0 240.8 197.6 197.6 231.0 188.3 188.3 220.3 178.3 178.3 208.6
SHC 177.8 213.8 249.9 171.2 206.0 240.8 164.1 197.6 231.0 156.4 188.3 220.3 148.0 178.3 208.6
67
THC 219.3 219.3 248.2 210.1 210.1 243.6 200.2 200.2 238.3 189.7 189.7 232.2 178.9 178.9 222.0
SHC 152.2 200.2 248.2 148.2 195.9 243.6 143.7 191.0 238.3 138.8 185.5 232.2 132.0 177.0 222.0
72
THC 237.4 237.4 237.4 227.6 227.6 227.6 216.8 216.8 216.8 205.2 205.2 205.2 192.7 192.7 192.7
SHC 103.4 152.2 201.1 99.9 148.7 197.5 96.1 144.8 193.5 92.1 140.7 189.2 87.7 136.1 184.5
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
