39
PERFORMANCE DATA (cont.)
569J*25D -- 524J*25 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
6000
Cfm
EA
(w
B
)
58
THC 220.0 220.0 247.0 212.1 212.1 238.2 203.4 203.4 228.5 193.7 193.7 217.7 182.8 182.8 205.5
SHC 193.0 220.0 247.0 186.0 212.1 238.2 178.3 203.4 228.5 169.8 193.7 217.7 160.1 182.8 205.5
62
THC 230.1 230.1 234.9 220.0 220.0 230.0 209.0 209.0 224.6 197.0 197.0 218.3 183.9 183.9 210.5
SHC 174.4 204.7 234.9 169.6 199.8 230.0 164.2 194.4 224.6 158.2 188.3 218.3 151.2 180.8 210.5
67
THC 251.0 251.0 251.0 239.9 239.9 239.9 227.9 227.9 227.9 214.6 214.6 214.6 199.9 199.9 199.9
SHC 142.4 172.3 202.2 137.6 167.6 197.6 132.5 162.6 192.7 126.9 157.1 187.3 120.9 151.1 181.3
72
THC 274.2 274.2 274.2 262.0 262.0 262.0 248.7 248.7 248.7 234.1 234.1 234.1 217.9 217.9 217.9
SHC 111.3 140.1 168.9 106.4 135.5 164.6 101.2 130.6 160.0
95.6 125.2 154.8 89.5 119.3 149.1
76
THC --- 294.4 294.4 --- 281.0 281.0 --- 266.4 266.4 --- 250.7 250.7 --- 233.4 233.4
SHC --- 113.0 146.0 --- 108.7 141.7 --- 104.6 133.3 --- 99.7 126.2 --- 94.1 122.4
7000
Cfm
EA
(w
B
)
58
THC 230.8 230.8 259.3 222.2 222.2 249.7 212.8 212.8 239.2 202.3 202.3 227.5 190.6 190.6 214.4
SHC 202.3 230.8 259.3 194.7 222.2 249.7 186.4 212.8 239.2 177.2 202.3 227.5 166.9 190.6 214.4
62
THC 236.4 236.4 255.9 225.9 225.9 250.3 215.3 215.3 241.3 203.8 203.8 231.2 191.3 191.3 220.8
SHC 186.6 221.3 255.9 181.4 215.8 250.3 174.2 207.7 241.3 166.3 198.7 231.2 158.0 189.4 220.8
67
THC 257.6 257.6 257.6 245.9 245.9 245.9 233.2 233.2 233.2 219.3 219.3 219.3 204.0 204.0 204.0
SHC 150.4 185.0 219.6 145.5 180.2 214.9 140.3 175.0 209.8 134.6 169.4 204.2 128.4 163.2 198.1
72
THC 281.0 281.0 281.0 268.1 268.1 268.1 254.2 254.2 254.2 238.8 238.8 238.8 222.0 222.0 222.0
SHC 114.4 148.1 181.8 109.5 143.4 177.3 104.2 138.4 172.5
98.5 132.8 167.2 92.3 126.8 161.3
76
THC --- 301.1 301.1 --- 287.2 287.2 --- 272.2 272.2 --- 255.7 255.7 --- --- ---
SHC --- 118.2 151.3 --- 113.9 143.1 --- 109.2 140.7 --- 104.0 136.6 --- --- ---
8000
Cfm
EA
(w
B
)
58
THC 239.6 239.6 269.4 230.5 230.5 259.2 220.5 220.5 248.0 209.4 209.4 235.6 197.0 197.0 221.7
SHC 209.9 239.6 269.4 201.8 230.5 259.2 193.0 220.5 248.0 183.3 209.4 235.6 172.3 197.0 221.7
62
THC 241.9 241.9 274.0 232.2 232.2 263.9 222.0 222.0 253.2 210.1 210.1 242.3 197.0 197.0 230.1
SHC 197.3 235.6 274.0 189.6 226.8 263.9 181.7 217.5 253.2 173.3 207.8 242.3 163.9 197.0 230.1
67
THC 262.7 262.7 262.7 250.5 250.5 250.5 237.3 237.3 237.3 222.9 222.9 222.9 207.1 207.1 214.0
SHC 158.0 197.1 236.3 153.0 192.2 231.4 147.6 186.9 226.1 141.8 181.1 220.3 135.5 174.7 214.0
72
THC 286.3 286.3 286.3 272.8 272.8 272.8 258.4 258.4 258.4 242.5 242.5 242.5 225.1 225.1 225.1
SHC 117.4 155.7 194.1 112.4 150.9 189.5 107.1 145.8 184.5 101.3 140.1 179.0
95.1 134.0 173.0
76
THC --- 306.6 306.6 --- 292.0 292.0 --- 276.5 276.5 --- --- --- --- --- ---
SHC --- 122.8 157.5 --- 118.2 154.2 --- 113.3 150.2 --- --- --- --- --- ---
9000
Cfm
EA
(w
B
)
58
THC 247.2 247.2 278.0 237.6 237.6 267.3 227.1 227.1 255.5 215.4 215.4 242.4 202.4 202.4 227.8
SHC 216.4 247.2 278.0 207.9 237.6 267.3 198.7 227.1 255.5 188.4 215.4 242.4 176.9 202.4 227.8
62
THC 249.4 249.4 281.3 239.3 239.3 272.2 227.9 227.9 262.4 215.4 215.4 251.6 202.3 202.3 236.4
SHC 202.5 241.9 281.3 195.4 233.8 272.2 187.7 225.1 262.4 179.2 215.4 251.6 168.3 202.3 236.4
67
THC 266.8 266.8 266.8 254.2 254.2 254.2 240.6 240.6 241.9 225.9 225.9 235.9 209.5 209.5 229.3
SHC 165.2 208.8 252.4 160.1 203.8 247.4 154.7 198.3 241.9 148.7 192.3 235.9 142.2 185.7 229.3
72
THC 290.4 290.4 290.4 276.6 276.6 276.6 261.8 261.8 261.8 245.4 245.4 245.4 227.6 227.6 227.6
SHC 120.1 163.0 205.9 115.1 158.2 201.2 109.8 152.9 196.1 103.9 147.2 190.5
97.6 141.0 184.4
76
THC --- 310.7 310.7 --- 295.9 295.9 --- --- --- --- --- --- --- --- ---
SHC --- 126.7 167.1 --- 122.1 163.2 --- --- --- --- --- --- --- --- ---
10,
000
Cfm
EA
(w
B
)
58
THC 253.7 253.7 285.4 243.7 243.7 274.2 232.7 232.7 261.9 220.5 220.5 248.2 206.9 206.9 233.0
SHC 221.9 253.7 285.4 213.1 243.7 274.2 203.5 232.7 261.9 192.7 220.5 248.2 180.8 206.9 233.0
62
THC 255.5 255.5 290.4 244.0 244.0 282.1 232.6 232.6 271.8 220.5 220.5 257.6 206.9 206.9 241.9
SHC 208.4 249.4 290.4 201.5 241.8 282.1 193.5 232.6 271.8 183.3 220.5 257.6 171.9 206.9 241.9
67
THC 270.1 270.1 270.1 257.2 257.2 262.7 243.3 243.3 257.0 228.0 228.0 250.8 211.4 211.4 243.3
SHC 172.1 220.0 267.8 166.9 214.8 262.7 161.4 209.2 257.0 155.2 203.0 250.8 148.3 195.8 243.3
72
THC 293.9 293.9 293.9 279.7 279.7 279.7 264.4 264.4 264.4 247.8 247.8 247.8 229.6 229.6 229.6
SHC 122.8 170.1 217.4 117.7 165.1 212.5 112.3 159.8 207.3 106.4 154.0 201.6 100.1 147.8 195.4
76
THC --- 314.3 314.3 --- 299.1 299.1 --- --- --- --- --- --- --- --- ---
SHC --- 130.6 175.9 --- 125.8 171.7 --- --- --- --- --- --- --- --- ---
--- Not operational
569J
