PERFORMANCE DATA (cont.)
569J*16A (Single Circuit)
CONDENSER ONLY RATINGS
SST (
_
F)
AIR TEMPERATURE ENTERING CONDENSER (
_
F)
80
85
95
105
115
125
20
TC
125.5
121.8
114.2
106.6
99.7
79.7
kW
10.5
11.2
12.6
14.2
16.0
17.5
SDT
98.6
103.4
113.0
122.7
134.9
136.0
25
TC
138.7
134.7
126.5
118.1
109.3
98.5
kW
10.7
11.4
12.8
14.3
16.0
17.9
SDT
100.0
104.7
114.2
123.6
132.9
140.5
30
TC
152.9
148.6
139.8
130.7
120.9
104.9
kW
10.9
11.6
13.0
14.6
16.2
17.8
SDT
101.4
106.2
115.5
125.0
133.6
139.4
35
TC
168.2
163.5
154.1
144.2
133.6
121.2
kW
11.2
11.8
13.2
14.8
16.5
18.1
SDT
102.9
107.5
117.0
126.2
134.8
142.1
40
TC
184.9
179.4
169.3
158.7
147.6
135.1
kW
11.5
12.0
13.5
15.1
16.8
18.5
SDT
105.2
108.9
118.5
127.7
136.7
144.5
45
TC
202.1
196.7
185.7
174.3
162.5
150.4
kW
11.7
12.4
13.9
15.6
17.5
19.6
SDT
106.4
111.2
120.9
130.7
140.4
150.2
50
TC
220.6
214.7
202.1
190.0
174.6
159.6
kW
11.9
12.6
13.9
15.4
16.9
18.5
SDT
107.2
111.7
120.4
129.4
136.9
144.9
NOTE:
Condensing unit only ratings are at 45
_
F SST and 95
_
F entering---air temperature. EER = 12.7
569J*16D (Dual Circuit)
CONDENSER ONLY RATINGS
SST (
_
F)
AIR TEMPERATURE ENTERING CONDENSER (
_
F)
80
85
95
105
115
125
20
TC
127.6
123.7
116.0
108.1
99.7
90.2
kW
10.0
10.6
11.9
13.4
14.9
16.6
SDT
96.0
100.5
109.8
119.2
128.3
137.0
25
TC
140.9
136.7
128.3
119.5
110.4
101.2
kW
10.0
10.6
11.9
13.4
14.9
16.6
SDT
96.0
100.5
109.8
119.2
128.3
137.0
30
TC
155.0
150.5
141.3
132.0
122.3
111.4
kW
10.4
11.0
12.3
13.7
15.3
17.0
SDT
98.7
103.3
112.4
121.5
130.6
139.1
35
TC
170.1
165.3
155.4
145.2
134.4
123.3
kW
10.6
11.2
12.5
14.0
15.5
17.2
SDT
100.1
104.7
113.8
122.8
131.7
140.4
40
TC
186.3
181.0
170.3
159.0
147.3
134.9
kW
10.8
11.4
12.8
14.2
15.8
17.4
SDT
101.6
106.1
115.1
124.0
132.8
141.4
45
TC
203.4
197.6
185.7
173.5
160.6
147.2
kW
11.1
11.7
13.0
14.4
16.0
17.6
SDT
103.2
107.6
116.5
125.4
134.0
142.5
50
TC
221.4
214.9
202.0
188.6
174.5
159.7
kW
11.4
12.0
13.3
14.7
16.2
17.9
SDT
104.8
109.2
118.0
126.7
135.2
143.5
NOTE:
Condensing unit only ratings are at 45
_
F SST and 95
_
F entering---air temperature. EER = 13.2
LEGEND:
kW
--- Compressor Power
SDT --- Saturated Discharge Temperature at Compressor (
_
F)
SST --- Saturated Suction Temperature (
_
F)
TC
--- Gross Cooling Capacity (1000 Btuh)
569J
