PERFORMANCE DATA (cont.)
569J*14D -- 524J*16 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
4500
Cfm
EA
(w
B
)
58
THC 145.6 145.6 164.1 140.4 140.4 158.2 134.6 134.6 151.7 128.4 128.4 144.6 121.6 121.6 137.0
SHC 127.1 145.6 164.1 122.5 140.4 158.2 117.5 134.6 151.7 112.1 128.4 144.6 106.2 121.6 137.0
62
THC 149.1 149.1 162.7 142.7 142.7 159.2 135.8 135.8 155.2 128.8 128.8 149.6 121.7 121.7 142.3
SHC 117.6 140.1 162.7 114.5 136.8 159.2 110.9 133.1 155.2 106.4 128.0 149.6 101.1 121.7 142.3
67
THC 161.2 161.2 161.2 154.4 154.4 154.4 147.0 147.0 147.0 138.8 138.8 138.8 130.1 130.1 130.1
SHC 94.6 117.4 140.3 91.8 114.6 137.5 88.8 111.6 134.5 85.6 108.4 131.2 82.1 104.9 127.7
72
THC 174.0 174.0 174.0 167.0 167.0 167.0 159.1 159.1 159.1 150.6 150.6 150.6 141.2 141.2 141.2
SHC 70.0 93.0 116.1 67.4 90.4 113.4 64.6 87.6 110.6 61.6 84.5 107.5 58.3 81.2 104.1
76
THC --- 184.6 184.6 --- 177.3 177.3 --- 169.1 169.1 --- 160.1 160.1 --- 150.3 150.3
SHC --- 72.9 96.6 --- 70.5 94.0 --- 67.7 91.2 --- 64.8 88.2 --- 61.6 85.0
5300
Cfm
EA
(w
B
)
58
THC 152.7 152.7 172.0 147.0 147.0 165.7 140.9 140.9 158.8 134.3 134.3 151.3 127.0 127.0 143.1
SHC 133.2 152.7 172.0 128.4 147.0 165.7 123.1 140.9 158.8 117.3 134.3 151.3 110.8 127.0 143.1
62
THC 153.6 153.6 176.8 147.4 147.4 171.5 141.0 141.0 165.0 134.4 134.4 157.2 127.1 127.1 148.6
SHC 126.2 151.5 176.8 122.0 146.8 171.5 117.2 141.0 165.0 111.6 134.4 157.2 105.6 127.1 148.6
67
THC 164.9 164.9 164.9 157.8 157.8 157.9 150.2 150.2 150.6 141.7 141.7 144.5 132.6 132.6 140.7
SHC 100.8 127.3 153.7 98.0 124.5 150.9 95.0 121.4 147.8 91.7 118.1 144.5 88.1 114.4 140.7
72
THC 177.6 177.6 177.6 170.3 170.3 170.3 162.2 162.2 162.2 153.3 153.3 153.3 143.7 143.7 143.7
SHC 72.4 99.1 125.7 69.9 96.5 123.1 67.0 93.7 120.2 64.0 90.6 117.1 60.6 87.2 113.7
76
THC --- 188.2 188.2 --- 180.6 180.6 --- 172.1 172.1 --- 162.9 162.9 --- 152.8 152.8
SHC --- 76.0 103.2 --- 73.5 100.6 --- 70.8 97.9 --- 67.9 94.9 --- 64.7 91.6
6000
Cfm
EA
(w
B
)
58
THC 157.7 157.7 177.7 151.8 151.8 171.1 145.5 145.5 163.9 138.5 138.5 156.1 130.9 130.9 147.5
SHC 137.6 157.7 177.7 132.6 151.8 171.1 127.0 145.5 163.9 120.9 138.5 156.1 114.3 130.9 147.5
62
THC 157.8 157.8 184.5 152.0 152.0 177.7 145.6 145.6 170.2 138.6 138.6 162.1 131.0 131.0 153.2
SHC 131.1 157.8 184.5 126.2 152.0 177.7 120.9 145.6 170.2 115.1 138.6 162.1 108.8 131.0 153.2
67
THC 167.2 167.2 167.2 160.1 160.1 162.1 152.3 152.3 158.9 143.7 143.7 155.3 134.6 134.6 151.3
SHC 105.9 135.5 165.0 103.1 132.6 162.1 100.0 129.5 158.9 96.7 126.0 155.3 93.0 122.1 151.3
72
THC 180.0 180.0 180.0 172.6 172.6 172.6 164.3 164.3 164.3 155.3 155.3 155.3 145.4 145.4 145.4
SHC 74.5 104.3 134.0 72.0 101.6 131.3 69.1 98.8 128.4 66.1 95.7 125.3 62.7 92.3 121.9
76
THC --- 190.6 190.6 --- 182.8 182.8 --- 174.2 174.2 --- 164.8 164.8 --- 154.6 154.6
SHC --- 78.6 108.9 --- 76.1 106.3 --- 73.4 103.5 --- 70.5 100.5 --- 67.3 97.3
6800
Cfm
EA
(w
B
)
58
THC 162.2 162.2 182.9 156.2 156.2 176.1 149.6 149.6 168.6 142.4 142.4 160.4 134.5 134.5 151.5
SHC 141.7 162.2 182.9 136.4 156.2 176.1 130.7 149.6 168.6 124.3 142.4 160.4 117.4 134.5 151.5
62
THC 162.4 162.4 190.0 156.3 156.3 182.9 149.7 149.7 175.1 142.5 142.5 166.6 134.6 134.6 157.3
SHC 134.9 162.4 190.0 129.9 156.3 182.9 124.4 149.7 175.1 118.4 142.5 166.6 111.8 134.6 157.3
67
THC 169.5 169.5 177.2 162.2 162.2 174.2 154.3 154.3 170.7 145.7 145.7 166.7 136.4 136.4 162.1
SHC 111.5 144.4 177.2 108.6 141.4 174.2 105.5 138.1 170.7 101.9 134.4 166.7 98.1 130.0 162.1
72
THC 182.2 182.2 182.2 174.6 174.6 174.6 166.2 166.2 166.2 157.0 157.0 157.0 146.9 146.9 146.9
SHC 76.8 109.9 143.1 74.2 107.3 140.5 71.4 104.4 137.6 68.3 101.3 134.5 65.0 97.9 131.0
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
7500
Cfm
EA
(w
B
)
58
THC 165.7 165.7 186.8 159.6 159.6 179.8 152.7 152.7 172.1 145.2 145.2 163.7 137.1 137.1 154.5
SHC 144.7 165.7 186.8 139.3 159.6 179.8 133.4 152.7 172.1 126.8 145.2 163.7 119.7 137.1 154.5
62
THC 165.9 165.9 193.9 159.6 159.6 186.7 152.8 152.8 178.7 145.3 145.3 169.9 137.2 137.2 160.4
SHC 137.8 165.9 193.9 132.6 159.6 186.7 126.9 152.8 178.7 120.7 145.3 169.9 113.9 137.2 160.4
67
THC 171.2 171.2 187.4 163.9 163.9 184.1 155.9 155.9 180.3 147.2 147.2 175.8 137.9 137.9 170.1
SHC 116.2 151.8 187.4 113.2 148.7 184.1 109.9 145.1 180.3 106.2 141.0 175.8 101.8 135.9 170.1
72
THC 183.8 183.8 183.8 176.0 176.0 176.0 167.5 167.5 167.5 158.2 158.2 158.2 148.0 148.0 148.0
SHC 78.7 114.8 150.9 76.1 112.2 148.3 73.3 109.3 145.4 70.2 106.2 142.2 66.9 102.8 138.7
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
--- Not operational
