34
PERFORMANCE DATA (cont.)
569J*16A -- 524J*25 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
6000
Cfm
EA
(w
B
)
58
THC 188.1 188.1 211.9 181.9 181.9 205.0 175.2 175.2 197.4 167.8 167.8 189.1 159.7 159.7 180.0
SHC 164.2 188.1 211.9 158.8 181.9 205.0 153.0 175.2 197.4 146.5 167.8 189.1 139.4 159.7 180.0
62
THC 189.5 189.5 216.5 182.5 182.5 212.0 175.4 175.4 205.1 168.0 168.0 196.4 159.8 159.8 186.9
SHC 154.7 185.6 216.5 150.8 181.4 212.0 145.7 175.4 205.1 139.5 168.0 196.4 132.7 159.8 186.9
67
THC 203.3 203.3 203.3 195.6 195.6 195.6 187.2 187.2 187.2 177.9 177.9 177.9 167.8 167.8 172.0
SHC 123.2 154.9 186.5 120.1 151.7 183.3 116.7 148.3 179.9 113.0 144.6 176.1 109.0 140.5 172.0
72
THC 218.9 218.9 218.9 210.9 210.9 210.9 202.0 202.0 202.0 192.1 192.1 192.1 181.3 181.3 181.3
SHC 90.2 122.0 153.8 87.2 119.0 150.8 84.0 115.8 147.5 80.5 112.2 143.9 76.7 108.3 140.0
76
THC --- 232.4 232.4 --- 224.0 224.0 --- 214.7 214.7 --- --- --- --- --- ---
SHC --- 95.8 128.2 --- 92.9 125.2 --- 89.8 122.0 --- --- --- --- --- ---
7000
Cfm
EA
(w
B
)
58
THC 195.8 195.8 220.6 189.4 189.4 213.4 182.3 182.3 205.4 174.5 174.5 196.6 165.8 165.8 186.9
SHC 171.0 195.8 220.6 165.3 189.4 213.4 159.1 182.3 205.4 152.4 174.5 196.6 144.8 165.8 186.9
62
THC 196.0 196.0 229.2 189.5 189.5 221.6 182.4 182.4 213.3 174.6 174.6 204.2 166.0 166.0 194.1
SHC 162.8 196.0 229.2 157.4 189.5 221.6 151.5 182.4 213.3 145.1 174.6 204.2 137.9 166.0 194.1
67
THC 207.2 207.2 207.2 199.2 199.2 201.0 190.5 190.5 197.4 181.1 181.1 193.5 170.7 170.7 189.2
SHC 131.3 167.8 204.3 128.1 164.6 201.0 124.6 161.0 197.4 120.9 157.2 193.5 116.8 153.0 189.2
72
THC 222.7 222.7 222.7 214.4 214.4 214.4 205.4 205.4 205.4 195.2 195.2 195.2 184.1 184.1 184.1
SHC 93.3 130.0 166.6 90.3 127.0 163.6 87.1 123.7 160.3 83.6 120.1 156.7 79.7 116.2 152.7
76
THC --- 236.5 236.5 --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- 100.0 137.1 --- --- --- --- --- --- --- --- --- --- --- ---
8000
Cfm
EA
(w
B
)
58
THC 202.0 202.0 227.6 195.3 195.3 220.1 187.9 187.9 211.8 179.8 179.8 202.6 170.7 170.7 192.4
SHC 176.4 202.0 227.6 170.5 195.3 220.1 164.1 187.9 211.8 157.0 179.8 202.6 149.1 170.7 192.4
62
THC 202.1 202.1 236.4 195.4 195.4 228.5 188.0 188.0 219.9 179.9 179.9 210.4 170.8 170.8 199.8
SHC 167.9 202.1 236.4 162.3 195.4 228.5 156.2 188.0 219.9 149.4 179.9 210.4 141.9 170.8 199.8
67
THC 210.1 210.1 221.2 202.1 202.1 217.8 193.3 193.3 214.0 183.7 183.7 209.7 173.2 173.2 204.8
SHC 138.9 180.0 221.2 135.7 176.7 217.8 132.2 173.1 214.0 128.3 169.0 209.7 124.0 164.4 204.8
72
THC 225.7 225.7 225.7 217.3 217.3 217.3 207.9 207.9 207.9 197.6 197.6 197.6 186.2 186.2 186.2
SHC 96.3 137.7 179.1 93.4 134.7 176.1 90.1 131.4 172.8 86.6 127.8 169.1 82.7 123.9 165.1
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
9000
Cfm
EA
(w
B
)
58
THC 207.1 207.1 233.4 200.2 200.2 225.6 192.6 192.6 217.0 184.1 184.1 207.4 174.8 174.8 196.9
SHC 180.8 207.1 233.4 174.8 200.2 225.6 168.2 192.6 217.0 160.7 184.1 207.4 152.6 174.8 196.9
62
THC 207.2 207.2 242.3 200.3 200.3 234.2 192.7 192.7 225.3 184.2 184.2 215.4 174.9 174.9 204.5
SHC 172.1 207.2 242.3 166.4 200.3 234.2 160.1 192.7 225.3 153.0 184.2 215.4 145.3 174.9 204.5
67
THC 212.6 212.6 237.2 204.5 204.5 233.5 195.6 195.6 229.3 186.0 186.0 224.4 175.5 175.5 217.9
SHC 146.2 191.7 237.2 142.9 188.2 233.5 139.2 184.3 229.3 135.1 179.7 224.4 130.1 174.0 217.9
72
THC 228.0 228.0 228.0 219.4 219.4 219.4 209.9 209.9 209.9 199.5 199.5 199.5 187.9 187.9 187.9
SHC 99.2 145.3 191.4 96.3 142.3 188.3 93.0 139.0 184.9 89.5 135.4 181.2 85.6 131.4 177.2
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
10,
000
Cfm
EA
(w
B
)
58
THC 211.4 211.4 238.2 204.3 204.3 230.2 196.4 196.4 221.4 187.8 187.8 211.6 178.1 178.1 200.7
SHC 184.6 211.4 238.2 178.4 204.3 230.2 171.5 196.4 221.4 164.0 187.8 211.6 155.5 178.1 200.7
62
THC 211.5 211.5 247.3 204.4 204.4 239.0 196.6 196.6 229.8 187.9 187.9 219.7 178.2 178.2 208.3
SHC 175.7 211.5 247.3 169.8 204.4 239.0 163.3 196.6 229.8 156.1 187.9 219.7 148.0 178.2 208.3
67
THC 214.6 214.6 251.9 206.6 206.6 247.8 197.8 197.8 242.7 188.2 188.2 235.9 178.3 178.3 223.5
SHC 152.9 202.4 251.9 149.4 198.6 247.8 145.4 194.0 242.7 140.5 188.2 235.9 133.1 178.3 223.5
72
THC 229.9 229.9 229.9 221.2 221.2 221.2 211.6 211.6 211.6 201.0 201.0 201.0 --- --- ---
SHC 102.1 152.7 203.3 99.1 149.7 200.2 95.9 146.4 196.9 92.3 142.7 193.1 --- --- ---
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
--- Not operational
569J
