APPLICATION DATA
Operating limits
Maximum outdoor temperature 125_F . . . . . . . . . . . . . . . .
Minimum return-air temperature (524JA) 55_F . . . . . . . .
Maximum return-air temperature (524JA) 95_F . . . . . . . .
Range of acceptable saturation
suction temperature 20 to 50_F . . . . . . . . . . . . . . . . . . .
Maximum discharge temperature 275_F . . . . . . . . . . . . . .
Minimum discharge superheat 60_F . . . . . . . . . . . . . . . . .
NOTES:
1. Select air handler at no less than 300 cfm/ton (nomin-
al condensing unit capacity).
2. Total combined draw of the field-supplied liquid line
solenoid valve and air handler fan contactor must not
exceed 22 va. If the specified va must be exceeded,
use a remote relay to control the load.
MINIMUM OUTDOOR-AIR OPERATING TEMPERATURE
UNIT
569J*
MINIMUM OUTDOOR TEMP ( _ F)
Std With MotorMaster I® Control†
07A 35
–20
08A 35
12A 35
14A 35
16A 35
25A 35
12D 35
14D 35
16D 35
25D 35
† Wind baffles (field-supplied and field-installed) are recommen-
ded for all units with MotorMaster Ir control. Refer to Low Ambi-
ent Temperature Control Installation Instructions for additional
information.
Refrigerant piping
IMPORTANT: Do not bury refrigerant piping
underground.
It is recommended that the refrigerant piping for all
commercial split systems include a liquid line solenoid
valve, a liquid line filter drier and a sight glass.
For refrigerant lines longer than 75 lineal ft, a liquid line
solenoid valve installed at the indoor unit and a suction
accumulator are required. Refer to the Refrigerant
Specialties Part Numbers table.
REFRIGERANT SPECIALTIES PART NUMBERS
UNIT
LIQUID LINE
SIZE (in.)
LIQUID LINE
SOLENOID VALVE
(LLSV)
LLSV COIL SIGHT GLASS FILTER DRIER
SUCTION LINE
ACCUMULATOR
569J*07 3/8 ALC---066208 AMG---24/50---60 HMI---1TT3 EK083S S---7063S*
569J*08
3/8 ALC---066208 AMG---24/50---60 HMI---1TT3 EK083S S---7063S*
1/2 ALC---066209 AMG---24/50---60 HMI---1TT4 EK164S S---7063S*
569J*12 1/2 ALC---066211 AMG---24/50---60 HMI---1TT4 EK164S S---7063
569J*14 5/8 ALC---066212 AMG---24/50---60 HMI---1TT5 EK305S S---7063
569J*16 5/8 ALC-066212 AMG-24/50-60 HMI-1TT5 EK305S S-7721*
569J*25 5/8 ALC-066212 AMG-24/50-60 HMI-1TT5 EK305S S-7721*
569J*16 1/2 ALC-066211 (Qty 2) AMG-24/50-60 HMI-1TT4 (Qty 2) EK164S (Qty 2) S-7063S (Qty 2)
569J*25 1/2 ALC-066211 (Qty 2) AMG-24/50-60 HMI-1TT4 (Qty 2) EK304S (Qty 2) S-7063S (Qty 2)
* Bushings required
