22
PERFORMANCE DATA (cont.)
569J*07A -- 524J*08 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
2250
Cfm
EA
(w
B
)
58
THC 71.6 71.6 80.7 69.1 69.1 77.9 66.2 66.2 74.6 63.2 63.2 72.2 --- --- ---
SHC 62.5 71.6 80.7 60.3 69.1 77.9 57.8 66.2 74.6 55.0 63.2 72.2 --- --- ---
62
THC 72.5 72.5 81.5 69.6 69.6 79.6 66.6 66.6 76.6 63.2 63.2 73.2 --- --- ---
SHC 58.5 70.0 81.5 56.9 68.2 79.6 54.6 65.6 76.6 52.1 62.7 73.2 --- --- ---
67
THC 78.1 78.1 78.1 74.8 74.8 74.8 71.2 71.2 71.2 67.0 67.0 67.7 60.9 60.9 64.5
SHC 46.9 58.7 70.5 45.6 57.4 69.1 44.1 55.9 67.6 42.4 54.2 66.0 40.1 52.0 63.8
72
THC 84.9 84.9 84.9 81.4 81.4 81.4 77.4 77.4 77.4 73.1 73.1 73.1 68.9 68.9 68.9
SHC 34.9 46.7 58.6 33.6 45.4 57.3 32.1 43.9 55.8 30.5 42.3 54.1 29.0 40.7 52.5
76
THC --- 90.6 90.6 --- 86.9 86.9 --- 82.5 82.5 --- 77.1 77.1 --- --- ---
SHC --- 37.1 49.1 --- 35.9 47.9 --- 33.5 43.4 --- 31.9 41.8 --- --- ---
2600
Cfm
EA
(w
B
)
58
THC 74.8 74.8 84.2 72.1 72.1 81.3 69.0 69.0 77.8 65.7 65.7 74.0 62.2 62.2 70.0
SHC 65.3 74.8 84.2 62.9 72.1 81.3 60.3 69.0 77.8 57.3 65.7 74.0 54.3 62.2 70.0
62
THC 74.9 74.9 87.2 72.1 72.1 84.3 69.1 69.1 80.8 65.7 65.7 76.8 61.7 61.7 72.1
SHC 62.0 74.6 87.2 60.0 72.1 84.3 57.4 69.1 80.8 54.6 65.7 76.8 51.2 61.7 72.1
67
THC 79.8 79.8 79.8 76.3 76.3 76.4 72.6 72.6 74.2 68.4 68.4 71.9 63.9 63.9 69.8
SHC 49.7 63.1 76.5 48.3 61.8 75.1 46.8 60.2 73.6 45.1 58.5 71.9 43.3 56.5 69.8
72
THC 86.5 86.5 86.5 82.9 82.9 82.9 78.8 78.8 78.8 74.3 74.3 74.3 69.5 69.5 69.5
SHC 36.0 49.4 62.9 34.7 48.1 61.6 33.2 46.6 60.1 31.6 45.0 58.4 29.9 43.3 56.7
76
THC --- 92.3 92.3 --- 87.7 87.7 --- --- --- --- --- --- --- --- ---
SHC --- 38.5 52.2 --- 36.5 49.2 --- --- --- --- --- --- --- --- ---
3000
Cfm
EA
(w
B
)
58
THC 77.6 77.6 87.4 74.8 74.8 84.2 71.5 71.5 80.6 67.9 67.9 76.5 64.9 64.9 73.1
SHC 67.7 77.6 87.4 65.3 74.8 84.2 62.5 71.5 80.6 59.3 67.9 76.5 56.7 64.9 73.1
62
THC 77.7 77.7 90.8 74.8 74.8 87.5 71.6 71.6 83.7 67.9 67.9 79.4 64.9 64.9 75.9
SHC 64.5 77.7 90.8 62.1 74.8 87.5 59.5 71.6 83.7 56.4 67.9 79.4 53.9 64.9 75.9
67
THC 81.2 81.2 83.0 77.7 77.7 81.6 73.9 73.9 80.0 69.6 69.6 78.0 65.3 65.3 74.4
SHC 52.7 67.8 83.0 51.3 66.4 81.6 49.8 64.9 80.0 48.0 63.0 78.0 44.5 59.4 74.4
72
THC 87.9 87.9 87.9 84.2 84.2 84.2 80.0 80.0 80.0 75.3 75.3 75.3 70.2 70.2 70.2
SHC 37.1 52.3 67.6 35.8 51.0 66.2 34.3 49.5 64.7 32.7 47.9 63.0 31.0 46.1 61.2
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
3400
Cfm
EA
(w
B
)
58
THC 79.7 79.7 89.8 76.8 76.8 86.4 73.4 73.4 82.7 69.6 69.6 78.4 64.8 64.8 73.0
SHC 69.6 79.7 89.8 67.0 76.8 86.4 64.1 73.4 82.7 60.8 69.6 78.4 56.6 64.8 73.0
62
THC 79.8 79.8 93.3 76.8 76.8 89.8 73.5 73.5 85.9 69.7 69.7 81.4 65.6 65.6 76.8
SHC 66.3 79.8 93.3 63.8 76.8 89.8 61.0 73.5 85.9 57.8 69.7 81.4 54.5 65.6 76.8
67
THC 82.3 82.3 88.8 78.8 78.8 87.3 74.9 74.9 85.5 70.6 70.6 83.2 --- --- ---
SHC 55.4 72.1 88.8 53.9 70.6 87.3 52.4 68.9 85.5 50.5 66.8 83.2 --- --- ---
72
THC 88.9 88.9 88.9 85.1 85.1 85.1 80.8 80.8 80.8 76.1 76.1 76.1 --- --- ---
SHC 38.2 55.0 71.9 36.9 53.7 70.5 35.4 52.2 69.0 33.8 50.5 67.3 --- --- ---
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
3750
Cfm
EA
(w
B
)
58
THC 81.5 81.5 91.9 78.5 78.5 88.4 75.0 75.0 84.5 71.1 71.1 80.1 64.7 64.7 72.9
SHC 71.2 81.5 91.9 68.5 78.5 88.4 65.5 75.0 84.5 62.1 71.1 80.1 56.5 64.7 72.9
62
THC 81.6 81.6 95.4 78.5 78.5 91.8 75.1 75.1 87.8 71.2 71.2 83.2 66.3 66.3 77.5
SHC 67.8 81.6 95.4 65.2 78.5 91.8 62.4 75.1 87.8 59.1 71.2 83.2 55.1 66.3 77.5
67
THC 83.2 83.2 93.9 79.7 79.7 92.2 75.8 75.8 90.3 71.5 71.5 87.7 --- --- ---
SHC 57.7 75.8 93.9 56.2 74.2 92.2 54.6 72.4 90.3 52.6 70.2 87.7 --- --- ---
72
THC 89.7 89.7 89.7 85.8 85.8 85.8 81.5 81.5 81.5 76.8 76.8 76.8 --- --- ---
SHC 39.1 57.4 75.7 37.8 56.0 74.3 36.3 54.5 72.7 34.7 52.8 71.0 --- --- ---
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
--- Not operational
569J
