40
PERFORMANCE DATA (cont.)
569J*25D -- 524J*28 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
7500
Cfm
EA
(w
B
)
58
THC 237.5 237.5 261.6 228.5 228.5 251.7 218.7 218.7 240.9 207.7 207.7 228.8 195.9 195.9 215.8
SHC 213.4 237.5 261.6 205.3 228.5 251.7 196.5 218.7 240.9 186.6 207.7 228.8 176.0 195.9 215.8
62
THC 241.6 241.6 261.6 230.8 230.8 255.7 220.1 220.1 246.2 207.9 207.9 236.1 196.1 196.1 222.6
SHC 201.2 231.4 261.6 195.7 225.7 255.7 188.0 217.1 246.2 179.8 207.9 236.1 169.5 196.1 222.6
67
THC 262.2 262.2 262.2 250.1 250.1 250.1 237.0 237.0 237.0 222.5 222.5 222.5 207.4 207.4 207.4
SHC 163.9 194.6 225.3 158.9 189.6 220.3 153.6 184.2 214.9 147.7 178.3 208.9 141.6 172.2 202.7
72
THC 285.5 285.5 285.5 272.2 272.2 272.2 257.9 257.9 257.9 242.1 242.1 242.1 225.6 225.6 225.6
SHC 125.1 156.0 186.9 120.2 151.0 181.9 114.9 145.7 176.5 109.2 139.9 170.6 103.2 133.8 164.5
76
THC --- 305.5 305.5 --- 291.1 291.1 --- --- --- --- --- --- --- --- ---
SHC --- 124.9 156.9 --- 120.0 151.8 --- --- --- --- --- --- --- --- ---
8750
Cfm
EA
(w
B
)
58
THC 248.0 248.0 273.2 238.3 238.3 262.5 227.7 227.7 250.8 215.9 215.9 237.8 203.3 203.3 223.9
SHC 222.8 248.0 273.2 214.1 238.3 262.5 204.6 227.7 250.8 194.0 215.9 237.8 182.6 203.3 223.9
62
THC 249.2 249.2 280.0 238.6 238.6 270.9 227.9 227.9 258.8 216.1 216.1 245.4 203.4 203.4 231.0
SHC 213.6 246.8 280.0 206.3 238.6 270.9 197.0 227.9 258.8 186.8 216.1 245.4 175.8 203.4 231.0
67
THC 267.7 267.7 267.7 254.9 254.9 254.9 241.2 241.2 241.2 226.3 226.3 228.3 210.6 210.6 221.6
SHC 174.8 210.1 245.4 169.7 204.9 240.2 164.2 199.3 234.5 158.2 193.2 228.3 151.8 186.7 221.6
72
THC 291.3 291.3 291.3 277.3 277.3 277.3 262.4 262.4 262.4 246.1 246.1 246.1 228.9 228.9 228.9
SHC 130.3 165.7 201.2 125.2 160.6 196.0 119.9 155.2 190.5 114.0 149.2 184.4 108.0 143.1 178.1
76
THC --- 311.4 311.4 --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- 130.1 166.5 --- --- --- --- --- --- --- --- --- --- --- ---
10,
000
Cfm
EA
(w
B
)
58
THC 256.5 256.5 282.5 246.1 246.1 271.1 234.9 234.9 258.8 222.4 222.4 245.0 209.1 209.1 230.4
SHC 230.4 256.5 282.5 221.2 246.1 271.1 211.1 234.9 258.8 199.9 222.4 245.0 187.9 209.1 230.4
62
THC 256.7 256.7 291.5 246.3 246.3 279.7 235.1 235.1 267.0 222.6 222.6 252.8 209.3 209.3 237.6
SHC 221.9 256.7 291.5 213.0 246.3 279.7 203.2 235.1 267.0 192.4 222.6 252.8 180.9 209.3 237.6
67
THC 271.7 271.7 271.7 258.6 258.6 259.0 244.6 244.6 253.0 229.2 229.2 246.3 213.3 213.3 238.9
SHC 185.1 224.9 264.6 179.8 219.4 259.0 174.1 213.6 253.0 167.8 207.1 246.3 161.1 200.0 238.9
72
THC 295.6 295.6 295.6 281.2 281.2 281.2 265.8 265.8 265.8 249.0 249.0 249.0 --- --- ---
SHC 135.2 175.0 214.9 130.0 169.8 209.6 124.6 164.2 203.9 118.6 158.2 197.7 --- --- ---
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
11,
250
Cfm
EA
(w
B
)
58
THC 263.5 263.5 290.3 252.7 252.7 278.3 240.9 240.9 265.3 227.9 227.9 251.0 214.0 214.0 235.7
SHC 236.8 263.5 290.3 227.0 252.7 278.3 216.4 240.9 265.3 204.7 227.9 251.0 192.2 214.0 235.7
62
THC 263.7 263.7 299.5 252.9 252.9 287.1 241.1 241.1 273.7 228.0 228.0 258.9 214.1 214.1 243.1
SHC 228.0 263.7 299.5 218.6 252.9 287.1 208.4 241.1 273.7 197.1 228.0 258.9 185.1 214.1 243.1
67
THC 275.0 275.0 282.7 261.6 261.6 276.8 247.2 247.2 270.3 231.8 231.8 262.6 216.0 216.0 251.8
SHC 194.9 238.8 282.7 189.4 233.1 276.8 183.4 226.8 270.3 176.6 219.6 262.6 168.2 210.0 251.8
72
THC 299.0 299.0 299.0 284.2 284.2 284.2 268.4 268.4 268.4 251.3 251.3 251.3 --- --- ---
SHC 139.8 184.0 228.1 134.6 178.7 222.7 129.0 173.0 216.9 123.1 166.8 210.6 --- --- ---
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
12,
500
Cfm
EA
(w
B
)
58
THC 269.5 269.5 296.9 258.2 258.2 284.4 245.9 245.9 270.9 232.4 232.4 256.0 218.0 218.0 240.1
SHC 242.2 269.5 296.9 232.0 258.2 284.4 221.0 245.9 270.9 208.8 232.4 256.0 195.9 218.0 240.1
62
THC 269.7 269.7 306.3 258.4 258.4 293.4 246.1 246.1 279.4 232.5 232.5 264.0 218.1 218.1 247.6
SHC 233.2 269.7 306.3 223.4 258.4 293.4 212.8 246.1 279.4 201.0 232.5 264.0 188.6 218.1 247.6
67
THC 277.8 277.8 299.7 264.1 264.1 293.2 249.7 249.7 285.6 234.5 234.5 274.3 218.8 218.8 261.2
SHC 204.0 251.8 299.7 198.2 245.7 293.2 191.6 238.6 285.6 183.1 228.7 274.3 173.4 217.3 261.2
72
THC 301.7 301.7 301.7 286.6 286.6 286.6 270.5 270.5 270.5 --- --- --- --- --- ---
SHC 144.3 192.6 241.0 139.0 187.2 235.5 133.4 181.5 229.6 --- --- --- --- --- ---
76
THC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
--- Not operational
569J
