Bryant LEGACY 569J - Manual (Page 35)

35
PERFORMANCE DATA (cont.)
569J*16D -- 524J*16 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
4500
Cfm
EA
(w
B
)
58
THC 168.2 168.2 185.7 161.9 161.9 181.8 156.0 156.0 175.2 149.4 149.4 167.8 143.0 143.0 160.7
SHC 145.7 165.7 185.7 142.0 161.9 181.8 136.7 156.0 175.2 130.9 149.4 167.8 125.3 143.0 160.7
62
THC 176.6 176.6 176.6 169.7 169.7 172.9 162.2 162.2 169.3 153.7 153.7 165.1 145.0 145.0 160.6
SHC 131.8 154.0 176.2 128.4 150.7 172.9 124.8 147.0 169.3 120.7 142.9 165.1 116.4 138.5 160.6
67
THC 192.7 192.7 192.7 185.3 185.3 185.3 177.2 177.2 177.2 168.0 168.0 168.0 158.8 158.8 158.8
SHC 108.2 130.1 151.9 104.9 126.9 148.9 101.5 123.5 145.5
97.6 119.7 141.8 93.7 115.9 138.1
72
THC 210.4 210.4 210.4 202.4 202.4 202.4 193.7 193.7 193.7 184.1 184.1 184.1 173.7 173.7 173.7
SHC
85.4 106.0 126.6 82.1 103.1 124.0 78.6 99.8 121.1 74.9 96.3 117.8 70.9 92.5 114.2
76
THC --- 224.8 224.8 --- 216.8 216.8 --- 207.7 207.7 --- 197.7 197.7 --- 186.5 186.5
SHC --- 86.9 111.7 --- 83.2 107.9 --- 80.0 104.8 --- 77.2 102.0 --- 73.8 96.1
5250
Cfm
EA
(w
B
)
58
THC 175.7 175.7 197.4 169.9 169.9 190.9 163.6 163.6 183.9 157.0 157.0 176.5 148.9 148.9 167.4
SHC 154.0 175.7 197.4 148.9 169.9 190.9 143.3 163.6 183.9 137.5 157.0 176.5 130.3 148.9 167.4
62
THC 181.7 181.7 192.0 174.2 174.2 188.1 166.6 166.6 184.0 157.8 157.8 179.0 149.9 149.9 172.2
SHC 141.0 166.5 192.0 137.2 162.7 188.1 133.4 158.7 184.0 128.8 153.9 179.0 123.4 147.8 172.2
67
THC 198.0 198.0 198.0 190.1 190.1 190.1 181.6 181.6 181.6 172.0 172.0 172.0 162.6 162.6 162.6
SHC 114.1 139.4 164.7 110.7 136.1 161.5 107.2 132.6 158.1 103.3 128.8 154.3
99.4 124.9 150.4
72
THC 215.8 215.8 215.8 207.4 207.4 207.4 198.2 198.2 198.2 188.3 188.3 188.3 177.5 177.5 177.5
SHC
87.6 112.0 136.4 84.4 108.9 133.5 80.8 105.6 130.4 77.1 102.0 127.0 73.1 98.2 123.3
76
THC --- 230.9 230.9 --- 222.1 222.1 --- 212.5 212.5 --- 202.0 202.0 --- 190.4 190.4
SHC --- 89.4 118.3 --- 86.8 115.7 --- 83.9 109.4 --- 80.7 103.0 --- 77.0 100.5
6000
Cfm
EA
(w
B
)
58
THC 182.7 182.7 205.3 176.5 176.5 198.5 169.9 169.9 191.0 162.2 162.2 182.4 154.7 154.7 174.0
SHC 160.0 182.7 205.3 154.6 176.5 198.5 148.7 169.9 191.0 142.0 162.2 182.4 135.3 154.7 174.0
62
THC 185.8 185.8 205.9 178.6 178.6 200.2 170.8 170.8 195.6 163.3 163.3 186.9 155.9 155.9 177.2
SHC 149.1 177.5 205.9 144.4 172.3 200.2 140.3 167.9 195.6 134.0 160.5 186.9 127.2 152.2 177.2
67
THC 202.0 202.0 202.0 193.9 193.9 193.9 185.0 185.0 185.0 175.4 175.4 175.4 165.2 165.2 165.2
SHC 119.6 148.2 176.9 116.3 144.9 173.6 112.6 141.3 170.1 108.7 137.5 166.3 104.6 133.4 162.2
72
THC 219.9 219.9 219.9 211.2 211.2 211.2 201.7 201.7 201.7 191.8 191.8 191.8 180.4 180.4 180.4
SHC
89.8 117.6 145.4 86.5 114.5 142.5 82.9 111.1 139.2 79.2 107.3 135.4 75.1 103.6 132.0
76
THC --- 235.1 235.1 --- 226.2 226.2 --- 216.2 216.2 --- 205.2 205.2 --- 193.3 193.3
SHC --- 92.9 121.7 --- 90.2 114.7 --- 87.1 112.8 --- 83.7 110.2 --- 79.9 107.2
6750
Cfm
EA
(w
B
)
58
THC 188.5 188.5 212.0 182.1 182.1 204.8 175.1 175.1 197.0 167.0 167.0 187.9 159.2 159.2 179.2
SHC 165.0 188.5 212.0 159.4 182.1 204.8 153.2 175.1 197.0 146.1 167.0 187.9 139.2 159.2 179.2
62
THC 189.7 189.7 216.7 183.3 183.3 208.6 176.4 176.4 200.6 168.7 168.7 191.6 159.2 159.2 185.9
SHC 155.5 186.1 216.7 149.8 179.2 208.6 144.0 172.3 200.6 137.5 164.6 191.6 132.4 159.2 185.9
67
THC 205.3 205.3 205.3 196.8 196.8 196.8 187.8 187.8 187.8 178.1 178.1 178.1 167.5 167.5 173.4
SHC 124.9 156.7 188.6 121.5 153.3 185.2 117.8 149.7 181.6 113.9 145.7 177.6 109.6 141.5 173.4
72
THC 223.3 223.3 223.3 214.3 214.3 214.3 204.6 204.6 204.6 194.2 194.2 194.2 182.6 182.6 182.6
SHC
91.8 122.9 154.0 88.5 119.7 151.0 84.9 116.3 147.7 81.2 112.7 144.2 77.1 108.7 140.3
76
THC --- 238.8 238.8 --- 229.4 229.4 --- 219.1 219.1 --- 207.9 207.9 --- 195.4 195.4
SHC --- 96.1 124.2 --- 93.2 122.1 --- 90.0 119.6 --- 86.5 116.7 --- 82.6 113.3
7500
Cfm
EA
(w
B
)
58
THC 193.5 193.5 217.7 186.9 186.9 210.2 179.6 179.6 202.1 171.5 171.5 193.1 163.1 163.1 183.6
SHC 169.3 193.5 217.7 163.5 186.9 210.2 157.1 179.6 202.1 150.0 171.5 193.1 142.6 163.1 183.6
62
THC 194.9 194.9 221.2 188.2 188.2 213.2 180.1 180.1 207.5 171.5 171.5 200.4 163.1 163.1 190.6
SHC 158.8 190.0 221.2 153.1 183.2 213.2 148.3 177.9 207.5 142.6 171.5 200.4 135.6 163.1 190.6
67
THC 207.9 207.9 207.9 199.3 199.3 199.3 190.0 190.0 192.6 180.1 180.1 188.7 169.2 169.2 184.2
SHC 129.9 164.9 199.8 126.4 161.4 196.4 122.7 157.7 192.6 118.7 153.7 188.7 114.4 149.3 184.2
72
THC 226.0 226.0 226.0 216.9 216.9 216.9 207.0 207.0 207.0 196.3 196.3 196.3 184.4 184.4 184.4
SHC
93.7 128.1 162.4 90.4 124.9 159.3 86.9 121.5 156.0 83.1 117.7 152.4 78.9 113.6 148.4
76
THC --- 241.7 241.7 --- 232.1 232.1 --- 221.6 221.6 --- 210.1 210.1 --- 197.2 197.2
SHC --- 98.9 131.0 --- 96.0 128.6 --- 92.7 125.9 --- 89.2 122.7 --- 85.2 119.2
--- Not operational
569J
