18

PERFORMANCE DATA (cont.)

569J*14A (Single Circuit)

CONDENSER ONLY RATINGS

SST (

_

F)

AIR TEMPERATURE ENTERING CONDENSER (

_

F)

80

85

95

100

105

115

20

TC

100.8

97.4

90.3

86.6

83.0

75.5

kW

8.48

8.97

10.00

10.53

11.07

12.19

SDT

98.0

102.6

111.8

116.4

120.9

130.0

25

TC

111.8

108.1

100.5

96.6

92.7

84.7

kW

8.66

9.15

10.20

10.75

11.31

12.47

SDT

99.6

104.1

113.2

117.7

122.3

131.3

30

TC

122.9

118.9

110.7

106.6

102.4

93.9

kW

8.84

9.35

10.41

10.97

11.55

12.75

SDT

101.3

105.8

114.8

119.3

123.8

132.7

35

TC

134.9

130.6

121.9

117.4

113.0

103.8

kW

9.05

9.55

10.64

11.21

11.80

13.03

SDT

103.1

107.6

116.5

120.9

125.4

134.2

40

TC

147.7

143.0

133.7

128.9

124.1

114.3

kW

9.27

9.78

10.88

11.47

12.07

13.32

SDT

105.1

109.5

118.3

122.8

127.1

135.8

45

TC

161.1

156.2

146.1

141.0

135.8

125.4

kW

9.51

10.03

11.15

11.73

12.34

13.61

SDT

107.2

111.6

120.3

124.7

129.0

137.5

50

TC

175.4

170.1

159.3

153.8

148.3

137.1

kW

9.78

10.30

11.42

12.02

12.63

13.92

SDT

109.5

113.8

122.4

126.7

130.9

139.4

NOTE:
Condensing unit only ratings are at 45

_

F SST and 95

_

F entering---air temperature. EER = 12.0

569J*14D (Dual Circuit)

CONDENSER ONLY RATINGS

SST (

_

F)

AIR TEMP ENT CONDENSER (

_

F)

85

95

100

105

115

120

20

TC

93.24

86.18

82.60

78.94

71.54

67.78

kW

9.22

10.36

10.96

11.56

12.76

13.37

SDT

104.4

113.3

117.8

122.2

130.9

135.2

25

TC

103.39

95.91

92.05

88.15

80.16

76.08

kW

9.42

10.60

11.21

11.83

13.10

13.73

SDT

106.1

114.9

119.3

123.7

132.3

136.6

30

TC

114.29

106.19

102.04

97.79

89.15

84.74

kW

9.63

10.84

11.46

12.10

13.41

14.07

SDT

107.8

116.6

120.9

125.3

133.8

138.0

35

TC

125.69

116.93

112.44

107.84

105.72

93.69

kW

9.84

11.07

11.71

12.36

13.70

14.38

SDT

109.5

118.2

122.6

126.8

135.2

139.4

40

TC

137.57

128.07

123.21

118.21

108.08

102.90

kW

10.05

11.30

11.95

12.61

13.98

14.68

SDT

111.3

119.9

124.2

128.4

136.7

140.8

45

TC

149.86

139.53

134.26

128.83

117.83

112.22

kW

10.27

11.53

12.18

12.85

14.24

14.95

SDT

113.1

121.6

125.8

130.0

138.1

142.1

50

TC

162.51

151.29

145.56

139.64

127.71

121.55

kW

10.50

11.76

12.42

13.09

14.48

15.20

SDT

114.9

123.3

127.5

131.6

139.6

143.5

NOTE:
Condensing unit only ratings are at 45

_

F SST and 95

_

F entering---air temperature. EER = 11.5

LEGEND:
kW

--- Compressor Power

SDT --- Saturated Discharge Temperature at Compressor (

_

F)

SST --- Saturated Suction Temperature (

_

F)

TC

--- Gross Cooling Capacity (1000 Btuh)

569J
