27 Memory card: MEMoryCard XL
A temperature programme with up to 40 ramps can be programmed on the MEMoryCard XL. Programming
can take place directly on the controller or through the PC program “Celsius 2007”.
For improved clarity it is recommended that extensive programmes are prepared graphically on the PC.
Where a MEMoryCard XL is programmed, it can be read only on the same oven type for which it has been
programmed.
Marking:
The text field of the MEMoryCard XL can be marked individually with text or diagram.
27.1 Programming the MEMoryCard XL from the oven
Insert the MEMoryCard XL into the slot in the control panel field.
The selected settings are written directly to the card and stored on it. After the card has been removed, the
programme stored internally in the controller becomes again activated.
27.2 Programming the MEMoryCard XL from a PC with the oven
Link the PC to the oven with an interface cable via the serial interface
(see Section: „Communication
interface“). Insert the MEMoryCard XL into the input slot in the control panel field.
Write protection:
The MEMoryCard XL can be provided with write protection using the PC program “Celsius 2007”. The
programme on the card can then not be altered on the controller.
27.3 Programming the MEMoryCard XL from a PC using the read-write unit
Using a read-write unit (which can be purchased separately) the MEMoryCard XL can be programmed
from a PC with “Celsius 2007” without any connection to an oven. It is important to ensure that the
MEMoryCard XL has to be inserted with the contact field pointing upwards towards the marking of the
read-write unit.
