Memmert CELSIUS 10.0 - Manual (Page 39)

39
CELSIUS 10.0
6.2.3 Saving and loading protocol data (*. pro)
If the option " Create Log File" is enabled when a tempering profile is run (see page 35 ), the
protocol values are saved to the protocol file (*. pro) selected. You may also write the actual
value curve with the corresponding tempering profile later on to a protocol file if the protocol
option is not enabled in the start dialog of the temperature programme.
The protocol can only be saved
later for as long as it is displayed
in the graphics window.
To create a file for the protocol dis-
played, select "File"→" Save Protocol
Data"→"To File (*. pro)". In the win-
dow appearing, you can select the
protocol file (button "File") and GLP
data that are to be recorded. This
option is automatically enabed if GLP
data have been set (see page 9 ).
Protocol data saved in this way can
be re-opened with "File"→" Load Pro-
tocol Data"→"From File" or
6.2.4 Loading protocol data from the internal MEMoryCard of the oven
If the oven is equipped with a MEMoryCard, protocol data are stored on it. They can be read
in with CELSIUS via "File"→" Load Protocol Data"→"From Internal MemoryCard" or
.
6.2.5 Loading protocol data (*.bin) from the ring protocol memory of the oven
The oven saves all values measured over a long period automatically in its internal ring
protocol memory. These measured values can be read in with CELSIUS ("File"→" Load Protocol
Data"→"From Device ( Ring Protocol Memory)" or
).
When they are first read out, the entire ring protocol memory is read out and saved as a file in
the format *.bin. This file is write-protected. The preset directory for ring protocol files varies
according to the operating system. This can be displayed via "Settings"→"Open Common Cel-
sius Directory". The ring protocol data are located in the subdirectory of this, "FlashProtocols".
Reading out the protocol memory for the first time may take some time (up to 15 min-
utes), depending on the device runtime.
