30
CELSIUS 10.0
If you move the mouse cursor over predefined coordinates
(links between two segments), it turns into a cross with four
arrows. If you hold the mouse button down, you can then
move the respective point on the x and/or y axis.
If a coordinate is created in a prohibited area or you want to
move it to such an area, the mouse cursor turns into a
no-entry sign. The coordinate jumps automatically back to its
previous position when you let go.
Changes to the graphical view are automatically updated
when you switch to the tabular view, and vice versa.
Ramp close statements
Each segment (ramp) of a tempering profile must
end with a close statement and be linked to the next
segment. These positions are represented by the blue
dots.
To run the selection dialog, move the
mouse cursor to one of the blue ramp end points and
press the right mouse button. The following ramp
close statements are available:
► normal: Resets the end point definition back to the standard value. At the
end of the ramp segment the oven continues straightaway with
the next ramp segment. If this is the final ramp segment, the
tempering profile is stopped and the connected oven is reset to
its default configuration.
loop count
delete
