7 Parameter reference
7.1 Parameter list | C15113
58
Lenze · 8400 protec · Drive-based safety · Software Manual · DMS 2.4 EN · 05/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15113
Parameter | Name:
C15113 | S bus: Filter control data
Data type: BITFIELD_32
Index: 9462
d
= 24F6
h
Bit-coded selection of the active bits in the safety bus control data
Display range
(min. hex value | max. hex value)
Value is bit-coded: Information
Bit 0 STO  Safe torque off
Bit 1 SS1  Safe stop 1
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 ES
 Safe enable switch
Bit 10 Reserved
Bit 11 OMS
 Safe operation mode selector
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Bit 16 PS_AIS
Restart acknowledgement via safety bus
Bit 17 PS_AIE Error acknowledgement via safety bus
Bit 18 Reserved
Bit 19 Reserved
Bit 20 Reserved
Bit 21 Reserved
Bit 22 Reserved
Bit 23 SSE
 Emergency stop function
Bit 24 Reserved
Bit 25 Reserved
Bit 26 Reserved
Bit 27 Reserved
Bit 28 Reserved
Bit 29 Reserved
Bit 30 Reserved
Bit 31 Reserved
 Read access  Write access  CINH  PLC-STOP  No transfer
