Lenze · 8400 protec · Drive-based safety · Software Manual · DMS 2.4 EN · 05/2013 · TD05
23
3 Safe configuration
3.1 Change parameter settings
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.1 Change parameter settings

How to change a parameter setting:
1. Select the parameter to be changed from the list.
2. Enter the new value into the Value column or select it from the defined options.
• Invalid or impermissible values are displayed in "red" in the input field.
• A selection from the list field may cause a deactivation of parameters which are now
irrelevant due to the selection (marked by a grey background colour).
3. Press or click into another box to accept the changed value.
• By pressing the key you can cancel the entry.

Tip!
The parameter settings of the drive-based safety system can also be displayed in the
»Engineer« parameter list (tab All parameters  category Safety option) and on the keypad.
Changes, however, are only possible via the Safe configuration tab!

Note!
Changed parameters of the drive-based safety system are not transmitted automatically
to the device, even if an online connection has been established!
The parameter set for the drive-based safety system is only safely transmitted when
clicking the Send button in the Safe transfer dialog box!
 Send safe data ( 45)
